[Rolling Storage Profile Machine] Heavy Duty Steel Supermarket Shelves Storage Rack Cold Rollformer Production Line

Name: [Rolling Storage Profile Machine] Heavy Duty Steel Supermarket Shelves Storage Rack Cold Rollformer Production Line
Brand: Zhongtuo
Availability: InStock

FOB Price

USD $70,000 - $100,000 / Set

1 Set(Min.Order)

Supply Ability 1 Set / Sets per Month
Port Tianjin
Payment Terms:T/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin:	Hebei, China	Brand Name:	Zhongtuo	Model Number:	SP505
After-sales Service Provided:	Engineers available to service machinery overseas

Product Description

Specifications

1.customize pillar for supermarket as required.
2.Low energy consuming and high working speed.
3.Strong tech team supported

[Rolling Storage Profile Machine] Heavy Duty Steel Supermarket Shelves Storage Rack Cold Rollformer Production Line

Specification:

1.low energy consuming like workforce
2.beautiful appearance;
3.High quality

Product Description

Zhongtuo Heavy Duty Steel Supermarket Shelves is a professional machine for making pillar in various types for supermaket. It suits for batch or mass producing supermake pillars. In the following part, I will show detail parameters of this machine.

Description	Introduction
Working efficiency	5-8m/min(not include cutting time)
Thickness of Material	2-3mm
Control system	Panasonic PLC
Uncoiler system	5Ton Manual Operation
Side- wheel	7 Sets
Servo feeding	1 set
Servo feeding power:	3.0kw
Punching	80T[70 times/min]
Forming by rolling	Roll 18 times
Roller material	GCR15 Aluminium processing after quenchin HRC58-62degree, Chrome plated
Shaft and the diameter of axle	45#Aluminium-processing ,diameter of axle=80mm
Main part power	18.5kw
Hydraulic motor power	5.5kw
Hydraulic pressure	12Mpa
Scissor material	Cr12Mov, herd steel HRC 58-62 degree
length tolerance	3m±1.5mm
voltage	380V, 50HZ,3 phase (adjustable by customer needs)
Frame form	arch type
Driving Method	Gear driving
Color	Yellow and blue(adjustable)
Size	lengthWidthHeight - 201.31.2m
Package	Nude package in 2*40GP container
Delivery date	60 working days
Payment Method	30% T/T in advance and balance 70% after inspection confirmation before shipment.

Main features of each part:

Shearing part:

(1) Shearing method:It adopts the hydraulic drive and automatic location to decide the dimension and cut the target products.

(2)Material:GCR12,Quenching Oil HRC58-62°C

(3)Length :automatically cut in specified length

(4)Error in length:±1.5mm

Counter:Panasonic

(1)Voltage:380V,50HZ,3phase(adjustable)

(2)control length automatically

(3)production counting automatically

(4)Computer controls length and quantity for finishing production in specified amount.

(5)Fix error automatically and accurately.

(6) control method:touch and button

(7)length unit:mm

Shaping machine features:

(1) Simple in construction,beautiful in appearance as it takes structural steel for welding in the whole. It is good in bearing capacity.

(2) For making sure the quality and capability of equipment, other parts of the machines were bought from well-known enterprise.

(3) It specifies length, shape, punching position, cutting position automatically and accurately, so the product is beautiful in head and end shape.

(4) Easy to install and use, it is good for factory use.

(5) low noise but high efficiency.

Work flow:

Uncoiling—Feeding—Leveling—Punching—Shaping—Shearing—Production

Check supermakert pillar machine from the following pictures:

Our Services

Supermaket pillar machine packaged Wiped Anti Rust Oil, Rollers and Shafters covered by waterproof film,Hydraulic station, PLC control Box, Spare parts and some small parts packed in plywood box. All Components Fixed by steel wire with Container.

Warranty

1). One year, and we will provide the technical support for the whole life.

2).Training: the buyer should charge of visa, return ticket, food and accommodation overseas

and USD50/person/day for salary.

3). Need one technicians

4).Training time: one week (contains the time of installation and adjustment)
