Home > Products > PU sandwich panel > Good heat Insulation Fireproof PU Sandwich roof Panel 75mm with High Quality

Good heat Insulation Fireproof PU Sandwich roof Panel 75mm with High Quality

FOB Price

USD $15 - $28 / Square Meter

400 Square Meters(Min.Order)

Supply Ability 3000 Square Meter / Square Meters per Month
Port Guangzhou Port
Payment Terms:T/T

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price

Product Details

Place of Origin:	Guangdong, China	Brand Name:	Ruosky	Model Number:	RS01056047
Panel Material:	Metal	Type:	Polyurethane Sandwich Panels

Product Description

The PU sandwich panel is an pre-engineered lightweight steel structure's wall and roofing main material with different thickness and variety of colors which is widely used for the roofing of large-scale workshop, warehouse and shed carport or used for the sound insulation project and firproofing project.

Advantages of PU sandwich panel as below:
1. Wide range of application: It can be used in the wall and roofing of factory, warehouse, office building, gymnasium, library, and used for sound insulation project and firproofing project etc.
2. Easy to assemble and disassemble and short construction period: All the components are completed in the factory prefabricated, so at the worksite just simple assembly will be finished the installation with short time. and cost savings for clients
3. Durable and easy to maintain: To plainting PE as a rust prevention material for product's surface treatment, it can long-term protection the product performance not be corroded under the heavy weather , thus it will be durable, and only needs to maintain simply
4.Handsome and Economic: To pursue a clear lines, smooth, modern and handsome in the appearance for a buildings will be very important in the field of modern arechitecture. and corrugated steel sheet as a building material with a variety of colors for wall and roofing will be most popular. moveover, the buliding cost also very lower than other building material.
5. Longer lifetime server: Safety and stable it could stand firmly more than 15 years.
6. Green and energy saving: Environmental protection, stable structure, earthquake resistance, water proofing, and energy saving. as the material can be cyclic utilization after disassemble

Product Name	Corrugated PU sandwich panel (for roofing)
Product Type	1040#(The mean is effective width 1040mm after processing)
Main Material	Steel steel with galvanized (GI) or Galvalume (GL) and PU Foam Material
Coating structure	Top+ Prime/Back, PE/EPOXY; 20- 25 microns/5-7 microns
Coating Material	Have PE (Polyester), SMP (Silicon Modified Polyster), PVDF (Polyvinylidene Fluoride), HDP ( High Durable Polyester ) for choose
Coating thickness	Top:17-25um back:5-8um,
Zinc Coating	45--275G/M2, and different weight of coating with different price and different quality
Yield Strength	370-380mpa
Tensile Strength	>300mpa
Color	Off-white, Sky-blue, Sea-blue, Ivory-white, Crimson and so on
Effective width	1040mm
Panel Thickness	50mm--200mm (50mm, 75mm, 100mm, 125mm, 150mm, 175mm, 200mm)
Thickness of metal sheet	Top:0.3mm-0.8mm, and bottom 0.3mm-0.4mm
Density	35-42kg/m3
U-Value (Heat transfer coefficient)	0.52w/㎡.k (based on the 50mm thickness )
K-Value (Heat conductivity	0.029W/m.K. (based on the 50mm thickness )
Tolerance	Thickness: +/-0.02 mm, Length and width: +/-2 mm; Zinc coating: +/-5%
Application	Roofing of warehouse, . large-scale workshop exhibition building, gymnasium and shed carport.and heat-insulation project and Cold room, Clean Room
Lifetime	10--20 years (different application have different lifetime, as the material will be different)

Product Photo

1. Product Real Picture Show

2. Product Sectional Drawing Show

Packing and Delivery

Product Application

1.Application

Corrugated EPS sandwich panel for steel structure warehouse roofing

Corrugated EPS sandwich panel for Carport house roofing

2. Necessary accessories for Installation

3. Assemble Detailed (for roof and wall)

Qatar-Doha Project

This project was export to Qatar-Doha on Dec.11th 2014, and some detailed information for this project as below:
1. Building area: 2380㎡
2. Two floors and one floor
3. for Staff dormitory
4. K house with 6P and 3P Height

We sent the technicians to assistance installation for whole warehouse project and 28days to finished all.

Indonesia-Surabya Project

This project was export to Indonesia-Surabya on Dec Augues.12th 2009, and some detailed information for this project as below:
1. Building area: 7890㎡
2. Two floors and one floor
3. for Staff dormitory and for office
4. K house with 6P and 3P Height
We sent the technicians to assistance installation for whole warehouse project and 30days to finished all.

China-Hainan Project

This project was export to Indonesia-Surabya on July 15th 2010, and some detailed information for this project as below:
1. Building area: 9350㎡
2. Two floors and one floor
3. for Staff dormitory and for office
4. K house with 6P and 3P Height
We sent the technicians to assistance installation for whole warehouse project and 38days to finished all.

Our Service

How to order for us?
Step 1: Send us your requirements by email or by Ali Tradermanager
Step 2: You will get a very competitive quoataion under your requirement from us.
Step 3: Negotiate and confrim each details for goods, get agreement and sign contract with us.
Step 4: Advanced payment and production
Step 5: Quality inspection to meet the requirements of contract.
Step 6: Balance payment and shipping
Step 7: Handing Shipping files to help clients get goods from transporter in time.
Step 8: Clients get goods and go into warranty time and afte-sale service

Why did our clients choose us without doubt? because of ......
1.Advanced machinery, well trained workers.
2.We have more than 10 years production, sales and export experience in the field of building material industry.
3.Unique designed, good quality, competitive price.
4.We have joined in Alibaba credit guarantee services (Trade assurance), it will be ensure that all of our client funds safe and not worry about the goods and service. Remarks: Trade assurance is a service by alibaba designed to creat trust in trade,providing buyers with a set of features and protections to help ensure suppliers honor important details of the contract. If supplier does not meet the shipping time or pre-shipment product quality requirements in the contract, will refund up to the covered amout for your order.

FAQ
1. Q: Are you trading company or manufacturer and Can you make color order ? A: We are factory, and Yes. We can coustomized the color according to your requirements.
2. Q: How long is your delivery time? A: Generally it is 5 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity and color.
3. Q: Do you provide samples ? is it free or extra ? A: Yes, we could offer the sample for free charge but do not pay the cost of freight.
4. Q: How do you guarantee the quality of the products? A: Strict product quality, unqualified resolute don't factory.This is the tenet of our factory. Every one of our products have strict testing procedures, must be 100% quality assurance.
5. Q: What is your terms of payment ? A: Payment<=2000USD, 100% in advance. Payment>=2000USD, 30% T/T in advance ,balance shouble be before shippment.
If you have any other questions, please feel free to contact us.
