Home > Products > Video Measuring Machine > 3D Manual Image Measuring System VMS-2010T

3D Manual Image Measuring System VMS-2010T

Name: 3D Manual Image Measuring System VMS-2010T
Brand: Jaten
Availability: InStock

FOB Price

USD $1,000 - $10,000 / Set

1 Set(Min.Order)

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price

Product Details

Place of Origin:

Guangdong, China

Brand Name:

Jaten

Model Number:

VMS-2010T

3D Manual Image Measuring System VMS-2010P

Description:

l Be Applied to Mechanical ,,Electronic ,Plastic Fields etc.

l Function of Data Processing,Displaying,Input,Output,

l With RS-232 Interface

l With Quick Measuring Software

l Obviously assistant laser position system

l UK Renishaw Probe

Specifications:

Model	VMS-1510P	VMS-2010P	VMS-2515P	VMS-3020P	VMS-4030P
Metal Table Size(mm)	354X228	404X228	450X280	506X356	606X466
Glass Table Size(mm)	210X160	260X160	306X196	350X280	450X350
X,Y-axis Travel(mm)	150X100	200X100	250X150	300X200	400X300
Z-axis Travel(mm)	200	200	200	200	300
Resolution(mm)	0.0005	0.0005	0.0005	0.0005	0.0005
X,Y-axis Accuracy(um)	≤3+L/200	≤3+L/200	≤3+L/200	≤3+L/200	≤3+L/200
Measuring Software	Standard	Standard	Standard	Standard	Standard
Net Weight(kg)	100	110	120	200	240
Dimensios(mm)	600x530x950	600x550x920	690x550x1020	780x600x1060	945x646x1096
Video System	1/3“ Color CCD Camera , 0.7~4.5 Zoom Lens, Video Total Magnification:30X~230X , Object View:7~1.1mm LED adjustable Light Source
Probe	UK Renishaw Probe
Power	180V~260V(AC),50HZ

Packing list:

Optional Items:
