Big Discount Grain Bucket Elevator Conveyor Used For Grain Silo Storage

  Big Discount Grain Bucket Elevator Conveyor Used For Grain Silo Storage

Belt bucket elevator is widely used in metallurgy, chemical industry, building materials, mine, grain and vegetable oil, food, fodder, plastic, medicine and other industries, it is designed for transporting granular, powder and small block of dispersed material vertically such as grain, coal, cement, raw meal, alumina, coke, foundry sand, wood chips and other materials where the application parameters require a belt elevator.( Grain Bucket Elevator)

( Grain Bucket Elevator)

( Grain Bucket Elevator)

Head features

1. The head cover is lined with a polymer wear-resisting plate, reducing the impact on the head when material discharge, improving service life;
2. Chimney type explosion-proof vent, vent side up to eliminate safety hazards, the head bearings with adapter sleeve Spherical roller bearings;
3. The head and base using 6mm steel plate, effectively ensure the overall rigidity hoist;
4. The head wheel coating using the plug-in plate, plastic surface prismatic grooves and Z shaped groove can be auxiliary, increasing friction and traction without increasing the contact area of head wheel.

Cylinder features

1. Using hydraulic coupling between reducer and motor, shortening motor start-up time; reducing the startup process to start the power, vibration and shock. While the high-speed rotation of the coupler with casing eliminate security risks can also be effective in preventing rainwater splashing into.
2. Adopting direct-hardened gear with an auxiliary transmission reducer can prevent the reversal of hoist downtime caused when elevator stops; when you close the main drive motor for maintenance, low speed hoist installation is completed by direct auxiliary drive reducer, it can easy to repair and maintenance for bucket elevator.

Base features

1. The wide feed hopper ensures smooth of material feeding, both sides are equipped with a feed inlet, the user can choose according to their inlet material properties.
2. Both sides of stand cleaning door adopt double gear rack structure, you can control the opening and closing size of the cleaning door by turning the hand wheel for easy cleanup of residual materials. Four bearings with stand, two axles improve strength.   ( Grain Bucket Elevator)

1. SRON bucket elevator using special mold pressing undercut strengthen multi-cylinder, high strength, good sealing, drive head wheel with fine rubber wheel, non-slip, wear-resistant, reinforced tensioning device, high-strength bucket belt and wear-resistant bucket
2. The assembly non-return device can effectively prevent downtime caused by blocking material, optional alarm and speed deviation detection system.  (Grain Bucket Elevator)

( Grain Bucket Elevator)
