Manufacturer Agricultural Irrigation HDPE Double-Wall Corrugated Pipe

FOB Price

USD $5 - $200 / Meter

100 Meters(Min.Order)

Supply Ability 40000 Metric Ton / Metric Tons per Month
Port Qingdao Shanghai
Payment TermsT/T L/C D/P D/A Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	China	Brand Name	MAX
Model Number	HDPE CORRUGATED PIPE	Material	PE
Specification	200mm-1200mm	Length	6m or customized
Thickness	2.3mm-57.3mm	Standard	GB/T 19472.1-2004

Product Description

Manufacturer Agricultural Irrigation HDPE Double-Wall Corrugated Pipe

Specifications

corrugated pipe price
Diameter: 200-1200mm
Stiff fitness: SN4 & SN8
>10 years professional manufacturer

Physical Properties

Items	Technical requirements
Ring stiffness	S1≥4KN/square meter, S2≥8KN/square meter
Impact strength(TIR)	≤10%
Ring flexibility	Test sample should be smooth, no reversed flexure , no crack, no delamination.
Oven test	no air bubble, no delamination, no crack
Creep rate	≤4

Brief introduction of HDPE Double Wall Corrugated Pipe

The main raw material for high density polyethylene (HDPE), smooth wall, the outer wall is a unique ring of corrugated, between the inner and outer wall hollow; product technology content is high, is a new type of environmentally friendly high-tech products. Products are mainly used for outdoor underground drainage, sewerage, communications cable bushing and farmland water irrigation, drainage, product transportation, loading and unloading facilities. It is one of the most ideal replacement product for cement pipe, cast iron pipe and glass steel pipe.

HDPE Corrugated Pipe Characteristics:

1. High strength, resistcompression , good impact resistance.
2. Good resistance to inhomogeneity precipitation , can be used for soft soil quicksand foundation .
3. Joins convenient, no leakage.
4. Smooth inner wall , small resistance, strong water capacity .
5. Corrosion resisting , no second pollution.
6. Light weight, easy to handle, construction convenient, low engineering cost.

HDPE Corrugated Pipe Applications:

1 Civil engineering

2 agricultural irrigation

3 conveying system for sewage plant

4 pre buried piping under highway

5 Ventilation piping for chemical industry and mine

6 power telecommunication cable conduit

7 bridge construction

HDPE Corrugated pipe Specification Table:

Inner diameter DN/ID(mm)	Outer diameter	Depth of socket
200	230	150
225	255	150
300	340	210
400	460	250
500	575	300
600	690	340
800	925	340
1000	1210	400
1200	1430	400
