Home > Products > Mixer and conveyor > screw plastic auger/feeder
screw plastic auger/feeder
USD $800 - $2,000
/ Set
1 Set(Min.Order)
- 200 Set / Sets per Month
- shanghai
- T/T Credit Card PayPal
You May Like
-
Plastic vertical dryer 1000KG/2000KG /3000KG
-
PVC Laboratory Mixer unit/Hot and cold mixer
-
Automatic screw feeding machine/equipment for sugar/powder/granules
-
automatic flexible auger conveyor for pvc
-
Automatic flexible auger pvc powder conveyor
-
used stainless steel screw auger conveyor/inclined auger conveyor
Product Details
| Condition: | New | Type: | Screw Conveyor | Material: | Stainless Steel |
| Material Feature: | Heat Resistant | Structure: | Conveyor System | Load Capacity: | 100 |
| Place of Origin: | Jiangsu, China | Brand Name: | BE | Model Number: | ZJF-700 Automatic Powder Feeder for pvc |
| Voltage: | 220V-600V | Power(W): | 2.2KW | Dimension(L*W*H): | According customer required |
| Certification: | CE ISO | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
ZJF-700 Automatic Powder Feeder
Model | ZJF-600 | ZJF-1000 | ZJF-2000 | ZJF-3000 |
Power(KW) | 0.75 | 1.1 | 1.5 | 1.5 |
Pipe Diameter(mm) | 76 | 102 | 120 | 140 |
Capacity(kg/h) | 600 | 1000 | 2000 | 3000 |
Size(cm) | 65*65*80 | 100*75*80* | 120*80*80 | 160*80*80 |
Weight(kg) | 80 | 150 | 200 | 300 |
Purpose and Scope:
The DTC series screw feeder to plastic processing machinery required ancillary equipment, a net powdered or granulated plastic materials automatically transported into the hopper, adjust the mixer device. Contact material made of stainless steel, raw materials during transport is completely free from contamination, do not bring any foreign objects, enabling the production process to achieve full closure automation.
Easy to install, and can be moved, such as multiple Banliao use the same material, just a platform feeder for feeding simultaneously multiple spices machines, eliminating the hassle of artificial feeding is feeding safer work , more time and more effort.
The main technical parameters:
| Model Specification | Unit | ZD-600 | ZD-1000 | ZD-2000 | ZD-3000 |
| Power supply | V | 380V50Hz | 380V50Hz | 380V50Hz | 380V50Hz |
| Feeding motor power | KW | 0.75 | 1.1 | 1.5 | 1.5 |
| Pusher motor power | KW | 0.75 | 0.75 | 1.75 | |
| Feeding tube diameter | mm | 76 | 102 | 120 | 140 |
| Feeding height | m | 3 | 3 | 3 | 3 |
| The feeding amount | kg/H | 600 | 1000 | 2000 | 3000 |
| Hopper capacity | kg | 80 | 150 | 200 | 250 |
| Box Size(L×W×H) | cm | 65×65×80 | 100×75×80 | 120×80×80 | 160×80×80 |
| Weight | kg | 80 | 150 | 200 | 300 |
