3- Feet Scraper Bottom Discharging Centrifuge (BE1200)
- 50 Set / Sets per Month
- Shanghai
- Credit Card PayPal
-
PSG Bottom Discharge Vertical Basket Centrifuge
-
18L bottle filling machine for water
-
BS-1 BOTTLE WASHING MACHINE BRUSHER/WASHING PARTS
-
5 gallon barrel de cap and brushing
-
20L bottle rising machine/19L bottle washer/5 gallon water bottle washing machine
-
20L bucket brushing machine/20L bucket washer/bottle washing
Product Details
| Brand Name: | BE | Model Number: | BE1200 | Place of Origin: | Jiangsu, China |
Product Description
Specifications
Scraper Bottom Discharging CentrifugeIndustrial centrifuge
High capacity centrifuge
Filtering centrifuge
Centrifuge wit
Features
1. PLC based control with programmable setup. Automatic operation with no operator attention monitors the whole process including feeding, first cycle filtration, cleaning, intensive filtration and discharging.
2. Inverter for speed regulation makes startup smooth. Relative centrifugal force is adjustable.
3. Dynamic braking. Non-touching braking doesn't produce dusts.
4. Leak-proof structure with silicone rubber or fluoroelastomers seals. It meets the requirement of general closed.
5. Programmed electromechanical feeding control.
6. Safety protection: rotation rate detection, vibration protection, motor overload and overheat protection, dual control with both electrical and mechanical to scrapers and the lifting device, interlocking the scraper and drum.
Our machinery can be used for chemical or pharmacy-manufacturing. It should be specifically chosen so as to meet the technical and economical requirements.
Technical Parameter
Items | models | ||
SGZ800 | SGZ1000 | SGZ1250 | |
Basket Dia(mm) | 800 | 1000 | 1250 |
Basket Volume(L) | 100 | 155 | 280 |
Max. charge(kg) | 135 | 210 | 420 |
Rotation Rate of Basket(r/min) | 1200 | 1000 | 900 |
Relative Centrifugal Force | 645 | 560 | 565 |
Power of Motor(kw) | 6.5/8 | 9/11 | 18.5/22 |
Overall Dimensions(l*w*h) (mm) | 1900*1550*2250 | 2150*1750*2400 | 2500*2000*2500 |
Weight(kg) | 2500 | 3500 | 4500 |
| Place of Origin: | Liaoning China (Mainland) | Brand Name: | BE | Model Number: | PSG |
| Model: | PSG800-PSG1600 | Bowl Diameter: | 800mm-1600mm | Speed: | 900rpm-1600rpm |
| Separation factor: | 650-1600 | Volume: | 100L-800L | Max Loading: | 135kg-1000kg |
| Motor: | 7.5kw-37kw | Weight: | 2000kg-9000kg | Operation: | Easy |
| Maintain: | Easy |
