800kVA frequency converter AC60-338000

Specifications

800kVA frequency converter AC60-338000
IGBT ,SMPS,radiator,electrolysis,absorptance capacitance ,driver board,copper plate

800kVA frequency converter  AC60-338000







1. Rating input voltage: Input power supply is 380V/50HZ factory electricity.

2. Rating output voltage: we can supply many single phase/triphase grades according to the requirement of the clients.

3. Rating output frequency: 60HZ/50HZ(can change freely) or400Hz

4. The precision and output voltage stability:  The allowance of the output frequency≤0.01Hz, stability

5. The stability of the output voltage: static state

6. 50%load output voltage transient changes :

7.variable-frequency power sources overload capacity:150% 10minutes, 200% 10s

8. Output voltage wave THD:THD≤1.2~2.8%





Model

13060

13100

33150

33300

331000

332000

333000

334500

336000

338000

Capacity(KVA)

6

10

15

30

100

200

300

450

600

800

Output limit currency

LOW(A)

16.8

27.6

41.6

84

276

none

HIGH(A)

8.4

13.8

20.8

42

138

260

400

600

800

1050

Circuit model

IGBT/SPWM pulse width adjustment mode

Output frequency

50Hz/60Hz  45-65Hz

Load stability

≤±1%

frequency stability

fixed-frequency≤±0.01%,frequency modulation≤±0.1%

Input voltage

220V±10%

380V±10%

Input phase

Single phase

Three phase four wire

Wave distortion

≤3%

Output

Wire voltage

low-grade:0-260V continuous-tuning; high-grade:0 - 520 V continuous-tuning

Phase voltage

low-grade:0-150V continuous-tuning; high-grade:0 -300 V continuous-tuning

Reaction time

≤2ms

DPI ( dots per inch )

frequency meter

0.1Hz

Voltage meter

0.1V

Current meter

0. 1A

Power meter

0.1W

Ammeter display

Frequency, voltage, current, power or PF 4 number display

Protection function

over voltage, over current, over temperature, over load, short circuit,  and automatic alarm

Insulation reactance

500Vdc 20MΩ

Pressure endurance insulation

1500Vac/5mA/1min

Cooling model

Compulsive fan cooling

Working temperature

-10℃-45℃

Relative humidity

0-90%(No condensing)

Altitude

1500meters







Best of system (B.O.S) is the global company that specializes in designing and manufacturing the power supply, which products of high reliability result from the most advanced technique of the aerospace and the military. We always take the technology of inverter as the core for many years,
the products include Conversion Power Supply (widely used electric power, communication, Locomotive), Frequency Conversion Power Supply, Aviation Military Special-purpose Power
Supply (400Hz frequency conversion, 28.5 Direct-current power), Uninterruptible Power Supply (UPS), Emergency Power Supply (EPS) and new energy generation green power supply (solar energy and wind power system) etc.
