frequency converter

FOB Price

USD $200 - $300 / Set

10 Sets(Min.Order)

Supply Ability 500 Set / Sets per Month
Port Qingdao

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Size	410440135mm		Output Current	2.1A-4.2A
Weight	20KG

Product Description

frequency converter

frequency converter features:

1.Have a high voltage, over current and short-circuit and overheat warning device
       2.16 bit microprocessors, the intelligent control and easy operation
       3.Low distortion interference,input and output are completely isolated , safe and reliable
       4.Unique transient waveforms value control and low distortion, high precision control
       5.Dynamic quick,when load changgees in 0 - 100% ,stationary response time <0.1S
       6.Provide world standard grid voltage,frequency,simulation testing all kinds of electrical products
       7.With no radiation,small harmonic ingredients and special treatment,no distracting
      8.The efficient up to above 85% wide applicable load,can be perceptual capacitive resistive load
       9.Import original german siemens IGBT high frequency inverter and deck mechanism
      10.Output voltage:low-grade:0-150 V,high grade: 0-300V adjustable continuously
      11.A machine has more function,surface and source are one:with the nearest 0.5 level output voltage, current and frequency and power the power factor watch

Technical parameters:

Model	Ac60-11005	Ac60-11010
Capacity	500VA	1KVA
Output limit currency	L:4.2A	L:8.4A
	H:2.1A	H:4.2A
Circuit model	IGBT/SPWM pulse width adjustment mode
Output frequency	50Hz/60Hz/45-65Hz
Load stability	≤±1%
frequency stability	fixed-frequency≤±0.01%,frequency modulation≤±0.1%
Input voltage	220V±10%
Phase	Single phase
Wave distortion	THD≤3%
Output voltage	low-grade:0-150V continuous-tuning; high-grade:0 - 300 V continuous-tuning
Reaction time	≤2mS
Ammeter display	Frequency, voltage, current, power or PF 4 number display
Protection function	over voltage, over current, over temperature, over load, short circuit, and automatic alarm
Insulation reactance	500Vdc 20MΩ
Pressure endurance	1800Vac/5mA/1minute
Cooling method	Compulsive fan cooling
Working temperature	-10°C-50°C
Relative humidity	0-90%(No condensing)
Altitude	1500meters
Dimension (W×L×H) mm	410×440×135
