RCC Concrete Culvert Pipe Making Machine
Overview of RCC Concrete Cuvlert Pipe Machine
XG(800-1500)*2000 RCC concrete pipe making machine is composed of four kinds of steel product :rack ,amplitude ,vibration system , demould and demise system.The machine weight is 2.5t, power is 6.2kw, this type machine is the first choice for concrete products company with the advantage of wide used, high effective and low energy-consuming .Concrete pipe making machine is used to produce concrete products with inner diameter 200-2000mm, length 1-2m , shape round square trilateral oval , joint of plaint spun collars Spigot Socket. The quality of pipe conform to GB/T11836.
Specification for Suspension Roller Concrete Pipe Machine
Type: suspension roller concrete pipe making machine
Productivity:8-10 pecs/ hour
Concrete Ratio:C30/ water(0.38):cement(1.1):sand(1.11):stone(2.72)
Power:45kw
Production process:
Adjusting the vibration system to the best station according to the size of concrete pipe and the vibration frequency of the raw material diameter. When putting materials , vibrate, on the effect of amplitude vibration , it need 1-5 minutes to form solid molding ,interval time is 1-5 seconds , it means demoulding automatically no matter how big the size is.After demoulding , the mold will be transfer to curing place by trolley , the concrete pipe machine will be used to produce the next one when the product put away.
When produce concrete pipes with different specification, it just needs a relevant mold to ensure the product same.
The machine can be installed underground, it has advantage of small voice, no pollution , safe and reliable.
Suspension roller concrete pipe machine apply to concrete pipes with small diameter, it has advantage of saving cost, high productivity.
Technical Parameters Of Suspension Roller Concrete Pipe Machine
Specification | Length (mm) | Diameter for draft(mm) | Power(kw) | size |
300*600 | 1000 | 120 | 7.5 | 2500*1500*1300 |
2000 | 120 | 15 | 3500*1500*1300 | |
3000 | 120 | 22 | 4500*1500*1300 | |
800-1200
| 2000 | 180 | 45 | 4500*2200*1800 |
2500 | 240 | 45 | 5000*2200*1800 | |
3000 | 240 | 55 | 5500*2200*1800 | |
4000 | 300 | 75 | 6500*2200*1800 | |
800-1500 | 2000 | 350 | 75 | 4500*2500*2080 |
2500 | 350 | 75 | 5000*2500*2080 | |
1200-2000 | 2000 | 500 | 90 | 5000*2800*2080 |
Reinforced Concrete Pipe External Load and Inner Wtare Pressure Test
Concrete Pipe Testing Machine
Application
Installation
Shandong Haiyu Industy Co., Ltd is leading manufacturer and supplier of Precast Concrete machinery, with R&D, manufacturing workshop, professional sales Team and service.
Our main products are: Water drainage concrete pipe machine and mold; Pre-stressed Concrete cylinder pipe machines also the Pre-stressed concrete electric pole and Pile machine line and steel moulds. Besides we also supply the wire cage welding machine, concrete mixing plant, and other equipments. Again, we provide the factory layout design, machine proposal, manufacturing, Installation& commissioning, worker training, trial production, one-stop service.
Since founded, our company has insisted on the principle of” Customer First, Faithful Manage-ment". We supply our customer with High Quality product, Reasonable Price, Good after sale service. With customer's trust and Support, Our machines have been sold to Indonesia, Vietnam, Nigeria, Kenyan, Ethiopia, Boliva , Ghana etc .
Look forward for the cooperation with you! Welcome you visit us!
