Home > Products > Angular Contact Ball Bearing > HCB7002-E-2RSD-T-P4S High Speed Spindle Bearing 15x32x9 mm Angular Contact Ball Bearings HCB7002.E.2RSD.T.P4S
HCB7002-E-2RSD-T-P4S High Speed Spindle Bearing 15x32x9 mm Angular Contact Ball Bearings HCB7002.E.2RSD.T.P4S
- 500000 Piece / Pieces per Month
- Shanghai guangzhou qingdao
- Credit Card PayPal
You May Like
-
7002AC Spindle Bearing Size 15x32x9 mm Angular contact ball bearing 7002 AC
-
N1012BTCCG1P4 Ball Screw Support Bearing High Precision Angular Contact Bearings N1012BTCCG1P4
-
Original Japan Brand High Precision Angular Contact Ball Bearing 7002CTYNSULP4
-
Angular Contact Ball Bearing 130BTR10HTYNDBLP4A
-
Angular Contact Ball Bearing 130BAR10HTYNDBLP4A
-
Angular Contact Ball Bearing 130BAR10STYNDBLP4A
Product Details
| Brand Name | KAIFU | Bore Size | 15, | |
| Outside Diameter | 32, | Model Number | HCB7002-E-2RSD-T-P4S | |
| Precision Rating | P6,P5,P4,P2,P1,P0, P6,P5,P4,P2,P1,P0 | Seals Type | ZZ/ZRS.RZ/RS. Open, | |
| Number of Row | Single Row | Place of Origin | Anhui, China |
Product Description
HCB7002-E-2RSD-T-P4S Spindle Bearing 15x32x9 mm Angular Contact Ball Bearing HCB7002.E.2RSD.T.P4S
Part of the bearing specification :
| Bearing No. | d | D | B |
| mm | mm | mm | |
| HCB7000-C-2RSD-T-P4S | 10 | 26 | 8 |
| HCB7001-C-2RSD-T-P4S | 12 | 28 | 8 |
| HCB7002-C-2RSD-T-P4S | 15 | 32 | 9 |
| HCB7003-C-2RSD-T-P4S | 17 | 35 | 10 |
| HCB7004-C-2RSD-T-P4S | 20 | 42 | 12 |
| HCB7005-C-2RSD-T-P4S | 25 | 47 | 12 |
| HCB7006-C-2RSD-T-P4S | 30 | 55 | 13 |
| HCB7007-C-2RSD-T-P4S | 35 | 62 | 14 |
| HCB7008-C-2RSD-T-P4S | 40 | 68 | 15 |
| HCB7009-C-2RSD-T-P4S | 45 | 75 | 16 |
| HCB7010-C-2RSD-T-P4S | 50 | 80 | 16 |
| HCB7011-C-2RSD-T-P4S | 55 | 90 | 18 |
| HCB7012-C-2RSD-T-P4S | 60 | 95 | 18 |
| HCB7013-C-2RSD-T-P4S | 65 | 100 | 18 |
| HCB7014-C-2RSD-T-P4S | 70 | 110 | 20 |
| HCB7015-C-2RSD-T-P4S | 75 | 115 | 20 |
| HCB7016-C-2RSD-T-P4S | 80 | 125 | 22 |
| HCB7017-C-2RSD-T-P4S | 85 | 130 | 22 |
| HCB7018-C-2RSD-T-P4S | 90 | 140 | 24 |
| HCB7019-C-2RSD-T-P4S | 95 | 145 | 24 |
| HCB7020-C-2RSD-T-P4S | 100 | 150 | 24 |
| HCB7021-C-2RSD-T-P4S | 105 | 160 | 26 |
| HCB7022-C-2RSD-T-P4S | 110 | 170 | 28 |
| HCB7024-C-2RSD-T-P4S | 120 | 180 | 28 |
| HCB7026-C-2RSD-T-P4S | 130 | 200 | 33 |
| HCB7028-C-2RSD-T-P4S | 140 | 210 | 33 |
| HCB7000-E-2RSD-T-P4S | 10 | 26 | 8 |
| HCB7001-E-2RSD-T-P4S | 12 | 28 | 8 |
| HCB7002-E-2RSD-T-P4S | 15 | 32 | 9 |
| HCB7003-E-2RSD-T-P4S | 17 | 35 | 10 |
| HCB7004-E-2RSD-T-P4S | 20 | 42 | 12 |
| HCB7005-E-2RSD-T-P4S | 25 | 47 | 12 |
| HCB7006-E-2RSD-T-P4S | 30 | 55 | 13 |
| HCB7007-E-2RSD-T-P4S | 35 | 62 | 14 |
| HCB7008-E-2RSD-T-P4S | 40 | 68 | 15 |
| HCB7009-E-2RSD-T-P4S | 45 | 75 | 16 |
| HCB7010-E-2RSD-T-P4S | 50 | 80 | 16 |
| HCB7011-E-2RSD-T-P4S | 55 | 90 | 18 |
| HCB7012-E-2RSD-T-P4S | 60 | 95 | 18 |
| HCB7013-E-2RSD-T-P4S | 65 | 100 | 18 |
| HCB7014-E-2RSD-T-P4S | 70 | 110 | 20 |
| HCB7015-E-2RSD-T-P4S | 75 | 115 | 20 |
| HCB7016-E-2RSD-T-P4S | 80 | 125 | 22 |
| HCB7017-E-2RSD-T-P4S | 85 | 130 | 22 |
| HCB7018-E-2RSD-T-P4S | 90 | 140 | 24 |
| HCB7019-E-2RSD-T-P4S | 95 | 145 | 24 |
Angular contact ball bearing:
Angular contact ball bearings are particularly suitable for carrying combined (axial and radial) loads. Sometimes, they also can carry pure axial load and operate in higher speed. Under radial load, axial component force will be produced which must be counteracted. So the bearings are normally adjust against a second bearing.
Application:
Application: Angular Contact Ball Bearing is widely used in cars, compressors, construction, electric motors, food industry, home appliances etc. As a rolling element, it turns the world.
Pictures show:
Product information:
| Product | HCB7002-E-2RSD-T-P4S Spindle Bearing 15x32x9 mm Angular Contact Ball Bearing HCB7002.E.2RSD.T.P4S |
| Precision Rating | ABEC1,ABEC3,ABEC5 |
| Clearance | C0,C2,C3,C4,C5 is available |
| Sealed Cap | Rubber or Metal |
| Paypal | Acceptable |
| OEM | Accept |
| Vibration Level code | V1,V2.V3 |
| Material | Gcr15 |
| Seals Type | ZZ/ZRS.RZ/RS. Open |
| Thickness | 9MM |
| Bore Size | 15 MM |
| Outside Diameter | 32MM |
| Fetures | Spindle Bearing |
| Regular export packing | Plastic drum+White box+ carton |
| industrial packaging or as your requiremen. | |
| MOQ | 1 pcs |
| Delivery Time | 1-3 days after receiving your payment |
| Payment Terms | L/C,T/T,Western Union,MoneyGram,Paypal |
| Port of shippment by sea | Shanghai,guangzhou,qingdao |
| Place of Origin | Anhui, China |
| Samples | Available |
Company introduction:
Anhui KaiFu Bearing import&export Co., Ltd. is Specializing in production the bearings ,
our bearing are widely used by big mechanical corporations. KaiFu bearing has high-quality management team,experienced pratitioners,and quick response and professional service team,and meanwhile is equipped with first-class automatic production lines as well as
complete quality management machines and system.
We sincerely hope to establish a good business relationship with you in the future.
Our Advantages:
1. Manufacturer,the most competive price and good quality
2. Perfect group of technical engineers give you the best support
3.Well-trained group of international sales provide the best service
4.OEM brand aviliable
5.Rich stock and quick delivery
Our factory:
1.small quantity, can delivery by global express: DHL TNT FedEx ARAMEX EMS UPS. this is door to door.
2.large quantity can delivery by air ,by sea, this is port to port.
Market Distribution:
80% of our products are for export, the products have been exported to many countries and regions, such as Russia, South America, Brazil, India, Europe, the Middle East, Asia, Central Asia, enjoys a good reputation at home and abroad.
Q:What is the warranty for your bearings?
A: Bearing from our company come with six months limited warranty under this condition: proper installation, operation and maintenance. If the malfunctions under warranty, you could contact us for replacement.The warranty dated from the date of the shipment.
Q: Does the bearing need to be cleaned before installation.
A: The bearings surface is coated with anti-rust oil. You must clean it with gasoline or kerosene. However, sealed bearings need to cleaning before installation.
Q: Can i customize the bearings?
A: Yes,sure .we provide customize- made service. You need to send us the drawings for our further handing.
