14L 3WF-3 Knapsack Power Mist Duster/ Power Sprayer

Specifications

shock absorption backcusion; rotating jetting pipe at 360 degrees;Easy stop switch; easy start(labour saved by 30%-50%)

Introduction

Knapsack mist duster is a kind of plant protecting machine which is light, flexible, and efficient. It is mainly used to kill the pests of cotton, wheat, rice, fruit trees and tea trees. It also can be used at small farm ground, hills, mountain area, livestock, greenhouse, flower-house, vegetable greenhouses, warehouse, and prevention of disease of the city.These series of machines have a compact structure, spray by wind. The volume house is directly connected with the engine. High-speed rotation of the impeller product high wind which can change the pesticide liquid near the nozzle to fog. It can meet different degree of flow work by change different nozzle.
Excepting the liquid, these series machines can also be used for duster, seed, and fertilizer.



Specification:





Model	3WF-3
Container Capacity(L)	14
Fuel tank capacity(L)	1.3
Net Weight(kg)	11
Range(m)	≥12
Mating power	1E40FP-3Z
Power(kw/r/min)	2.13/7500
Packing Dimension(mm)	532x452x730







Features:

1, Aluminum alloy impeller ,  high speed rotation, long spray range.

2, With big filling opening, convenient to fill in pesticide and water,

3, Reliable engine, powerful and easy to maintain.

4, Recoil starting. Easy to start.

5, Foamed plastic back cushion absorbs vibration, soft and comfortable.
