Product Details
Place of Origin: | Henan, China | Brand Name: | ZS | Model Number: | Casing head |
Type: | Other, Casing Head | Machine Type: | Drilling Equipment | Certification: | API |
Material: | Stainless Steel | Processing Type: | Forging | Use: | Well Drilling |
Product Description
Oilfield Wellhead Equipment API 6A Casing Head Spool
We could supply all models of casing head that suitable to land and subsea wellhead
And we carry out API 6A standard. And API 17K standard
Our products could match the following brand:
FMC, CAMERON, CONTROL FLOW, DKG, DRILLQUIP, CE, VECTOGREY, WEA Oilfield Wellhead Equipment API 6A Casing Head Spool THERFORD, WEIRSEABOARD
WOOD GROUP, WOM, STREAM FLO. EXPRO, MI SWACO, T3
The connectionsize and pressure is following:
Casing size | Top flange | Threaded Bottom | Welded Bottom | Slip Bottom | |||||||
SIZE | WP | A | B | C | A | B | C | A | B | C | |
7" | 11" | 3,000 | 470 | 162 | 280 | 470 | 162 | 280 | 470 | 162 | 280 |
8-5/8" | 11" | 2,000 | 450 | 203 | 280 | 450 | 203 | 280 | 450 | 203 | 280 |
3,000 | 470 | 203 | 280 | 470 | 203 | 280 | 470 | 203 | 280 | ||
5,000 | 500 | 203 | 280 | 500 | 203 | 280 | 500 | 203 | 280 | ||
9-5/8" | 11" | 2,000 | 450 | 230 | 280 | 450 | 230 | 280 | 450 | 230 | 280 |
3,000 | 470 | 230 | 280 | 470 | 230 | 280 | 470 | 230 | 280 | ||
5,000 | 500 | 230 | 280 | 500 | 230 | 280 | 500 | 230 | 280 | ||
10,000 | 540 | 230 | 280 | 540 | 230 | 280 | 540 | 230 | 280 | ||
13-5/8" | 5,000 | 490 | 230 | 350 | 490 | 230 | 350 | 490 | 230 | 350 | |
10-3/4" | 11" | 2,000 | 450 | 259 | 280 | 450 | 259 | 280 | 560 | 259 | 280 |
3,000 | 470 | 259 | 280 | 470 | 259 | 280 | 470 | 259 | 280 | ||
5,000 | 500 | 259 | 280 | 500 | 259 | 280 | 500 | 259 | 280 | ||
10,000 | 560 | 255 | 280 | 560 | 255 | 280 | 560 | 255 | 280 | ||
11-3/4" | 13-5/8" | 2,000 | 470 | 279 | 350 | 470 | 279 | 350 | 470 | 279 | 350 |
3,000 | 470 | 279 | 350 | 470 | 279 | 350 | 470 | 279 | 350 | ||
5,000 | 520 | 279 | 350 | 520 | 279 | 350 | 520 | 279 | 350 | ||
16-3/4" | 3,000 | 444 | 279 | 422 | 444 | 279 | 422 | 444 | 279 | 422 | |
5,000 | 457 | 279 | 422 | 457 | 279 | 422 | 457 | 279 | 422 | ||
12-3/4" | 13-5/8" | 5,000 | 520 | 312 | 350 | 520 | 312 | 350 | 560 | 312 | 350 |
13-3/8" | 13-5/8" | 2,000 | 470 | 318 | 350 | 470 | 318 | 350 | 470 | 318 | 350 |
13-3/8" | 13-5/8" | 3,000 | 470 | 318 | 350 | 470 | 318 | 350 | 560 | 318 | 350 |
5,000 | 520 | 318 | 350 | 520 | 318 | 350 | 520 | 318 | 350 | ||
16-3/4" | 3,000 | 470 | 318 | 425 | 470 | 318 | 425 | 470 | 318 | 425 | |
5,000 | 520 | 318 | 425 | 520 | 318 | 425 | 520 | 318 | 425 | ||
16" | 16-3/4" | 2,000 | 445 | 386 | 425 | 445 | 386 | 425 | 445 | 386 | 425 |
3,000 | 445 | 386 | 425 | 445 | 386 | 425 | 445 | 386 | 425 | ||
5,000 | 457 | 386 | 425 | 457 | 386 | 425 | 457 | 386 | 425 | ||
20" | 20-1/4" | 2,000 | 490 | 482 | 510 | 490 | 482 | 510 | 490 | 482 | 510 |
20-3/4" | 3,000 | 490 | 482 | 527 | 490 | 482 | 527 | 630 | 482 | 527 | |
21-1/4" | 2,000 | 490 | 482 | 540 | 490 | 482 | 540 | 490 | 482 | 540 |
Puyang Zhongshi Group Company Ltd was founded in 1996,which is the restructured enterprise of Central Plains oilfield branch company of SINOPEC . The company registered capital is 6083 million yuan,with annual output value 200 million yuan, 580 employees, including more than 160 technical and administrative staff. Oil machinery is our main products, the leading products include pumping unit,subsurface sucker rod pump, wellhead (Christmas Tree), pressure vessels,drilling solid control series products and cementing accessories, We had attained ISO 9001 in 1998 and API Certificates in 2002 .
All products purchased in our company are guaranteed to keep in good repair for one year. If quality problems happen in guarantee period, our company will maintain for free. Additionally, our company provides technical support and fittings for life. After-sales service isn't restricted by time and we will assign technical personnel to solve your problems immediately after receiving telephone and hear feedback idea of users and deal with them in time. If you are caught in some problems when using our products, welcome to contact us at any time.
