qinme Union special industrial sewing machine Jeans sewing

Union special 35800 Heavy duty material jeans industrial sewing machine

Features

Direct-drive cutter crank arm type fell seam sewing machine

1. Suitable for sewing denim jacket with side seams, cuffs sewn seam, jeans.

2.Through the lab tug, it  can feed strongly.

3.It adopts the top Direct-drive cutter crank and make it work very well.

4.It is made in arm type

Application:

Specifications:

Name                             QM-35800

Sewing form                  three needles six threads sewing machine

Function                        medium~ high thickness: jeans, labor jacket, uniform

Max sewing speed        4500rmp

Stitch length  6.4mm(1/4”)

Sewing length                          2.1mm~3.6mm(standard 3.2mm)

Needle/standard sewing      UY130GS(standard)/Nm140(#22)

Needle bar area            33mm

Stitch conductor           6conductors

Weight(head)                23.5kg

Presser foot lift             Max 9mm(6.5mm for factory)

Tug on the feed width  11.9mm

Feed adjustment method     Main feed: slide length adjustments

                                       Poor feed: lever adjustment        No poor feed

Lubricating method      Automatic rotary pump oil

Machine oil                   Juki machine oil NO.18

Installation method      Aid drive assembly  MT103 mounted on the machine

What included in the box?
Machine head, base, cleaner, table, stand and other necessary parts and tools.Standard accessory

Carton size: 67*37.5*49cm,  Gross Weight:81.00Kg  Packaged by hard foams inside, and cardboard box outside.

Why us:
1. We focus on researching and producing sewing machine since 1993.
2. We passed ISO9001:2008 quality management system certification.
3. We have 5 master technicians available during business hours if you have any Questions.
4. We offer special design services to meet your personal demands.
Warranty: one year     long lifespan

Watch video:

  /watch?v=vppvtG82EjM

Copy this link to youtube and watch video

Contact:
Email: leoho#  ( please change # to @ )

Ph/ WhatsApp:  +8618126328400

Wechat / Skype:  leoheyulei

Union special 35800 industrial sewing machine

About us:

      Our company was established in March, 1993, and have more than 10 years' development. Our factory located in Shenzhen, covers an area of 4800 square meters. We are specialized in producing industrial sewing machines. In 2011, we passed ISO9001:2008 quality management system certification. We have established a comprehensive management system from model design and development, part production and assembly machine commissioning to after-sales tracking service. Our company has earned good reputation in China's sewing machine and accessory area.
