Home > Industrial Equipment & Components > Power Transmission Parts > Transmission Belt > GY-12N3 1.2MM Yellow/green Transmission Belt Dryer Belt Nylon Belt Conveyor Price is Competitive
GY-12N3 1.2MM Yellow/green Transmission Belt Dryer Belt Nylon Belt Conveyor Price is Competitive
US$ 10 - 50
MOQ: 50 Square Meters
Key Specifications
Get Latest Price
Standard or Nonstandard:
Nonstandard
Type:
Flat Belt
Material:
Nylon
Payment & Shipping
Payment Methods:
Port of Shipment:
SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
4.0MM Yellow/green Rubber Flat Transmission Belt High Energy Saving and China Antistatic BletUS$ 5 - 150MOQ: 50 Square Meters -
2mm Thick Cotton Power Transmission Belt/tin Can Machine BeltUS$ 45.00 - 57.00MOQ: 40 Square Meters
-
1.0mm Nylon Base Driving Flat Belt for Textile MachineUS$ 10 - 200MOQ: 50 Square Meters
-
2.0mm Nylon Base Rubber Conveyor Belt for Textile MachineryUS$ 30.00 - 38.00MOQ: 50 Square Meters
-
1.0mm Rubber Polyamide Transmission BeltUS$ 17.00 - 24.00MOQ: 50 Square Meters
Standard or Nonstandard
Nonstandard
Type
Flat Belt
Material
Nylon
Place of Origin
Jiangsu, China
Brand Name
SEJONE
Model Number
GY-12N3
Specifications
Oil resistant,abrasion resistant,
high flexibility,
no distortion.
Product Description
- APPLICATION FIELD: Ring spinning frames, Crimper machine, Double twister, etc.
- FEATURES: Abrasion resistant, Frictional coefficient almost keeps at a constant level .
- TECHNICAL DATA
| ITEM NO. | GY-12N3 | ANTISTATIC | NO |
| THICKNESS (MM) | 1.2 | TRACTION LAYER MATERIAL | PA |
| BELT WEIGHT (KG/M2) | 1.42 | FRICTION COVER MATERIAL | NBR |
| MANUFACTURING WIDTH (MM) | 500 | FRICTION COVER COLOR | YELLOW |
| TENSILE FORCE FOR 1% ELONGATION PER UNIT OF WIDTH (N/MM) | / | REVERSE COVER MATERIAL | NBR |
| MIN PULLEY DIAMETER (MM) | / | REVERSE COVER COLOR | GREEN |
| WORKING TEMPERATURE (OC) | -20~80 | JOINING METHOD | THERMOFIX |
- DETAILED IMAGES
Packaging & Shipping
- PACKAGING
- Put the paper tube inside.
- Transparent plastic film applied. To protect belts from damp environment.
- Bubble plastic film applied. To prevent belts from pressure and squeeze.
- The outer packing: Durable woven bag or customized wooden case.
- SHIPPING
- FOB ShangHai.
- FCA anywhere of China.
- CIF anywhere.
Company Information
- Our factory was established in 2003. We have more than 11 years' experience in this business.
- We specialized in the production of Power transmission belt, Conveyor belt, Machine tapes, Spindle tapes, Folder-gluer belts and Seamless belts. These belts are widely used in Textile industry, Paper and Printing industry, Packaging machinery, Wood-processing, Food and Tobacco industry, Parcel and Mail sorting,etc.
- We are in conformity with ISO 9001:2008 standard.
- We are manufacturer as well as exporter. We can help you to lower your purchase cost.
- We have new products development. --- Self-owned lab and annually new products scheme.
- We have very good geographic advantage. --- We are only 2 hours away from Shanghai.
Our Services
- Samples available.
- Joints making --- Flexproof, Thermofix, Fast-joining, Steel buckles.
- Punching, Crosspiece, rubber bars, rubber baffles etc.
- We provide OEM service, ODM service and OBM service.
Recommend products
ITEM NO. | THICK NESS (MM) | TRAC TION LAYER | REVERSE COVER COLOR | REVERSE COVER MATERIAL | FRICTION COVER COLOR | FRICTION COVER MATERIAL | JOINING METHOD | ANTI STATIC | TEMPERA TURE (OC) | MAX WIDTH (MM) |
GY-10N3 | 1.0 | PA | Green | NBR | Yellow | NBR | Thermofix | NO | -20~80 | 500 |
GY-12N3 | 1.2 | PA | Green | NBR | Yellow | NBR | Thermofix | NO | -20~80 | 500 |
GY-15N5 | 1.5 | PA | Green | NBR | Yellow | NBR | Thermofix | NO | -20~80 | 500 |
GY-20N8 | 2.0 | PA | Green | NBR | Yellow | NBR | Thermofix | NO | -20~80 | 500 |
GY-20N6 | 2.0 | PA | Green | NBR | Yellow | NBR | Thermofix | NO | -20~80 | 500 |
GY-22N10 | 2.2 | PA | Green | NBR | Yellow | NBR | Thermofix | NO | -20~80 | 500 |
GY-25N10 | 2.5 | PA | Green | NBR | Yellow | NBR | Thermofix | NO | -20~80 | 500 |
GY-25N8 | 2.5 | PA | Green | NBR | Yellow | NBR | Thermofix | NO | -20~80 | 500 |
GY-25N12 | 2.5 | PA | Green | NBR | Yellow | NBR | Thermofix | NO | -20~80 | 500 |
GY-30N10 | 3.0 | PA | Green | NBR | Yellow | NBR | Thermofix | NO | -20~80 | 500 |
GY-32N12 | 3.2 | PA | Green | NBR | Yellow | NBR | Thermofix | NO | -20~80 | 500 |
GY-30N15 | 3.0 | PA | Green | NBR | Yellow | NBR | Thermofix | NO | -20~80 | 500 |
GY-35N15 | 3.5 | PA | Green | NBR | Yellow | NBR | Thermofix | NO | -20~80 | 500 |
GY-40N10 | 4.0 | PA | Green | NBR | Yellow | NBR | Thermofix | NO | -20~80 | 500 |
GY-40N15-A | 4.0 | PA | Green | NBR | Light yellow | NBR | Thermofix | YES | -20~80 | 500 |
GY-50N12 | 5.0 | PA | Green | NBR | Yellow | NBR | Thermofix | NO | -20~80 | 500 |
GY-25N12-A | 2.5 | PA | Green | NBR | Light yellow | NBR | Thermofix | YES | -20~80 | 500 |
GY-35N15-A | 3.5 | PA | Green | NBR | Light yellow | NBR | Thermofix | YES | -20~80 | 500 |
FAQ
- Payment terms --- 30%-50% TT in advance. The balance against B/L copy.
- Skype account --- noya1983
