aluminum casement window type with wood and white color

FOB Price

USD $400 - $580 / Set

100 Sets(Min.Order)

Supply Ability 35 Ton / Tons per Month
Port FOSHAN/GUANGZHOU/SHENZHEN
Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Guangdong, China	Grade	6000 Series
Temper	T3-T8	Application	Other, Door & Window
Shape	T - Profile	Alloy Or Not	Is Alloy
Model Number	60 serie	Brand Name	YT

Product Description

1.Aluminium Alloy	6063, 6061.

2.Temper:	T4,T5,T6

3.Surface treatment:	Mill Finished, Anodizing, Electrophoresis, Powder coating

4.Color:	Silver, champagne, bronze, gold, white, black, and so on

5.Length:	10mm-7200mm

6.Shape&dimension	the design we have or customized according to your design

7.Packing:	our normal package is clean film ,pearl cotton and hot shrink ,but we can do according to your requirements

8.Certification:	ISO9001,ISO14001,CE.

9.Standard:	China high precision GB5237-2008

Yatai Aluminium Profile Technical Standard:

Yatai Aluminium Profile Chemical Composition(%)

Alloy	Si	Fe	Cu	Mn	Mg	Cr	Zn	Ti	Other	Aluminium
6061	0.40-0.80	0.70	0.15-0.40	0.15	0.80-1.20	0.04-0.35	0.25	0.15	0.15	remainder
6063	0.2-0.60	0.35	0.10	0.10	0.45-0.90	0.10	0.10	0.10	0.10	remainder

Yatai Mechanical Property

Alloy	Temper	Tensile Strength	Yield Strength	Elongation
6063	T5	>160MPa	>110Mpa	>8%
6063	T6	>205MPa	>180Mpa	>8%
6061	T6	>265MPa	>245Mpa	>8%

Yatai Aluminium Profile 's Surface Treatment Specification:

Anodized	Oxide Layer (average thickness)	AA10	≥10μm
Anodized		AA15	≥15μm
Electrophoretic Coating	Composite Layer(average thickness)	Level A	≥21μm
Electrophoretic Coating		Level B	≥16μm
Powder Coating	Layer Hardness		≥3H
	Gird Test		≥0
	Minimum local thickness		≥40μm
	indentation hardness		≥80
	Gird test		≥0

Yatai Aluminium Profile Technical Standard:

Yatai Aluminium Profile Chemical Composition(%)

Alloy	Si	Fe	Cu	Mn	Mg	Cr	Zn	Ti	Other	Aluminium
6061	0.40-0.80	0.70	0.15-0.40	0.15	0.80-1.20	0.04-0.35	0.25	0.15	0.15	remainder
6063	0.2-0.60	0.35	0.10	0.10	0.45-0.90	0.10	0.10	0.10	0.10	remainder

Yatai Mechanical Property

Alloy	Temper	Tensile Strength	Yield Strength	Elongation
6063	T5	>160MPa	>110Mpa	>8%
6063	T6	>205MPa	>180Mpa	>8%
6061	T6	>265MPa	>245Mpa	>8%

Yatai Aluminium Profile 's Surface Treatment Specification:

Anodized	Oxide Layer (average thickness)	AA10	≥10μm
Anodized		AA15	≥15μm
Electrophoretic Coating	Composite Layer(average thickness)	Level A	≥21μm
Electrophoretic Coating		Level B	≥16μm
Powder Coating	Layer Hardness		≥3H
	Gird Test		≥0
	Minimum local thickness		≥40μm
	indentation hardness		≥80
	Gird test		≥0

GLASS OPTIONS:

Glass tyle	Tempered/frosted/reflective/Low-E glass/Tinted/Clear/Craft or with geometric- bar/ patterned glass//as customized
Single glass	-5/6/8/10 (clear/ tempered glass)
Mid-hollow glass	(5mm+9a+5mm)/(5mm+12a+5mm)/--(6mm+6a+6mm)/6+6A/9A/12A /27A+6mm
Laminated glass	5+ 0.38/0.76/1.52PVB+5mm//6+0.76/1.14PVB+6mm

Product reference

Please Contact:

1.How do you charge the mold fee?

Incase we need to open new mold for your ordered profiles ,the mold fee will be refounded to customers when your order quantity reaches a certain amount.

2.How do you quote price ,per ton or per meter?

We provide more than two pricing modes

3.What is the differences between theoretical weight and actual weight?

Actual weight is the actual weight including packaging

Theoretical weight is identified according to the drawing,calculated by of the weight of each meter multiplied by the length of profile

4.How long it will take you to make samples?

1-2 days after the tools making in general.
