Specifications
1. High temperature viton rubber2.thick:1mm-50mm
lor:color
4.moq:20kg
5.high quality and low price
shore A 20-80 translucent HTV unvulcanized uncured silicone rubber
| H-7120 | H-7130 | H-7140 | H-7150 | H-7160 | H-7170 | H-7180 |
Density g/cm3 | 1.08± 0.02 | 1.09± 0.02 | 1.12± 0.02 | 1.14± 0.02 | 1.16± 0.02 | 1.20± 0.02 | 1.20± 0.02 |
Hardness Shore A | 20±2 | 30±2 | 40±2 | 50-53 | 60-63 | 70-73 | 80±2 |
Tensile Strength (Mpa), ≥ |
4.5 |
6.0 |
7.0 |
7.5 |
7.5 |
7.0 |
6.5 |
Tear Strength (KN/m),≥ |
8.5 |
13 |
15 |
18 |
18 |
17 |
17 |
Tension Set %, ≤ | 10 | 8.0 | 8.0 | 7.0 | 7.0 | 7.0 | 6.0 |
Elongation at break %, ≥ |
850 |
600 |
450 |
400 |
300 |
220 |
160 |
Linear contraction% |
3.6± 0.15 |
3.5± 0.15 |
3.4± 0.15 |
3.3± 0.15 |
3.25± 0.15 |
3.15± 0.15 |
3.1± 0.15 |
1. The HD 78 series viton rubber compound is widely used in molding.
2. Mainly suitable for base compound of miscellaneous goods, such as keypad,watch,band,case and sheet.
3. The shore hardness is 50 to 80.
4. The viton rubber compound is with ISO9001:2010,SGS certificate.
5. The viton rubber compound are factory direct, so we can provide reasonable price. We enjoy a good reputation in producing silicone rubber compound at home and abroad.
6. The viton rubber has an excellent performance in high temperature resistance, low temperature, bad weather.
