Digital Camera kit gb watches 16CH CCTV DVR with 800TVL CMOS IR bullet Cameras dvr kit
Camera Specification
| Model No. | BE-ICD70 | BE-ICD70S | BE-ICD100C | BE-ICD80M | BE-ICD80C | BE-ICD60 | BE-ICD42 |
| Image Sensor | 1/3"Sony | 1/3"Sony | 1/3"CMOS | 1/3"CMOS | 1/4"CMOS | 1/3"Sony | 1/3"Sony |
| ICX673BK CCD | ICX811AK CCD | PC1099 | PC3089 | MT9V139 | ICX639BK CCD | ICX633BK CCD | |
| Horizontal Resolution | 700TVL, Low Illumination, DWDR, OSD, DNR, PM, MD | 700TVL, Low Illumination, DWDR, OSD, DNR, PM, MD | 1000TVL | 800TVL | 800TVL | 600TVL, Low Illumination, DWDR, OSD, DNR, PM, MD | 420TVL |
| Pixels | PAL: 976 (H)×494(V) | PAL: 976 (H)×582(V) | 962 (H)×504(V) | 762 (H)×504(V) | PAL: 720 (H)×576(V) | PAL: 795 (H)×596(V) | |
| NTSC : 976 (H)×582 (V) | NTSC : 976 (H)×582 (V) | NTSC : 720 (H)×480 (V) | NTSC: 811 (H)×508 (V) | ||||
| Television Standards | PAL/ NTSC | ||||||
| IR LED | 36PCS of 5mm IR LED | ||||||
| IR Distance | 30m | ||||||
| Lens | Board Lens 3.6 mm/F2.0 | ||||||
| Sync System | Internal | ||||||
| Usable Illumination | 0.01Lux/F2.0 | ||||||
| IR Power On | CDS Auto Control | ||||||
| S/N Ratio | ≥65dB (AGC OFF) | ≥54dB (AGC OFF) | |||||
| Gamma Correction | 0.45 | ||||||
| Video Output | Composite Signal (1.0Vp-p, 75Ω) | ||||||
| Scanning System | PAL: 625 Lines, 50 Field/Sec; NTSC: 525 Lines, 60 Field/Sec | ||||||
| Electronic Shutter | Auto: PAL 1/50-1/100,000Sec; NTSC 1/60-1/100,000Sec | ||||||
| Operation Temperature | -10°C ~ +50°C, RH: 95% Max | ||||||
| Storage Temperature | -20°C ~ +60°C, RH: 95% Max | ||||||
| White Balance | Auto | ||||||
| Power Supply | DC12V | ||||||
| Dimension | 135(W) x62(H) x120(D)mm | ||||||
DVR Main Features:
- Including 1xUSB Mouse,1x IR Remote Controller
- 16CH DVR, Standard H.264 video compression,
- 16CH BNC Video input/2CH BNC output,1CH VGA(1440*900),1CH HDMI(1080P)
- 2CH RCA Audio input/1CH RCA output
- 16CH CIF real time recording
- Support USB flash driver,Network,movable HDD backup
- Support Multi-language OSD
- Support Windows,Symbian,IPhone,Blackberry,Android monitoring
- 4CH alarm input,1CH alarm output
- Cloud Technolog (P2P) support
DVR Specificatin:
| Model | BE-9016HC |
System | Main processor | HIS chipset Hi3520D |
Display | Display screen | 1/4/8/9/16 screen |
Video | Video standard | PAL(625 lines,50HZ);NTSC(525lines,60HZ) |
Monitor quality | Monitor:D1;VGA:1080P ;HDMI:1080P | |
Playback quality | Max support 1080P under HVR and NVR mode;Max support D1 under DVR mode | |
Encode capability | 16CH CIF real time | |
Decode capability | 16CH CIF | |
Motion detection | Each channel can set 192(16*12)detection area;can set multi-level of flexibility | |
Audio | Audio compression | G.711A |
Record and playback
| Record mode | Manual,alarm,motion detection,timing |
Local playback | Support 16CH CIF playback synchronously | |
Video search | Time,date,event,channel search | |
Storage and back up | Space occupation | Video:CIF 4~5G/day*channel, D1 16~20G/day*channel; |
Video storage | Local HDD ,Network | |
Back up mode | Network backup,USB portable HDD,USB DVD-RW,SATA DVD-RW | |
Interface | Video input | 16CH BNC |
Video output | 1CH BNC,1CH VGA,1CH HDMI | |
Audio input | 2CH RCA | |
Audio output | 1CH RCA | |
Alarm input | 4CH | |
Alarm output | 1CH | |
Network port | RJ45 10M/100M self-adaptive Ethernet port | |
PTZ control | 1 RS485;support multi kinds of PTZ Protocol | |
USB port | 2*USB2.0 | |
HDD port | 1 SATA(max support 3TB) | |
Wireless port | 3G,WIFI(extension via USB port) | |
CMS | CMS software | Support (up to 255 DVR simultaneously) |
other | Tour | Support |
Remote controller | Support | |
Working temperature | -20°C-60°C | |
Working humidity | 10%-90% | |
Power | 12V/3A | |
Dimension | 325(W) x52(H) x230(D) |
MOQ:
1. Sample order >=1pcs
2. Normal Order >=10pcs per model after sample test
OEM Service:
We could offer OEM and ODM services for our clients.
Delivery Time:
Sample order 3-5 working days, bulk order 7-15 working days.
Quality Warranty:
2 years for free repair. The warranty time starts from the shipping date from our factory
Price Term:
FOB Shenzhen
Payment:
T/T, Paypal, Western Union, MoneyGram, L/C are all available
