solar aircon

Type

NES60

6-200M

6-210M

6-220M

6-230M

6-240M

Max-Power

Pm(W)

200

210

220

230

240

Power Tolerance

(%)

±3

±3

±3

±3

±3

Max-Power Voltage

Vm(V)

28.7

29.2

29.8

30.0

30.6

Max-Power Current

Im(A)

6.97

7.19

7.39

7.66

7.84

Open-Circuit Voltage

Voc(V)

36.0

36.4

36.8

37.0

37.5

Short-Circuit Current

Isc(A)

7.75

7.86

8.00

8.18

8.38

Max-System Voltage

(VDC)

1000

Cell Efficiency

ηc(%)

14.1

14.8

15.5

16.2

16.9

Module Efficiency

ηm(%)

12.2

12.8

13.4

14.1

14.7

Number,type and arrangement of cells

60 pcs. Mono-Crystalline Silicon(6×10)

Cell Size

(mm)

156×156

No. of Bypass Diodes

(pcs.

6

Max. Series Fuse

(A)

11

Pm Temperature Coefficient

(%/)

-0.45

Isc Temperature Coefficient

(%/)

0.05

Voc Temperature Coefficient

(%/)

-0.35

NOCT-Nominal Operating Cell Temperature

()

47±2

Cable type ,Diameter and Length

4mm² ,TUV certified,1000mm

Type of Connector

Compatible Type III and Type IV

Dimension    A×B×C

(mm)

1650×992×46

Weight

(Kg)

19.5

No. of Draining Holes In Frame

8

Glass , Type and Thickness

High Transmis ., Low Iron, Tempered Glass 3.2mm.

Packing Configuration

2 pcs./box or 20 pcs./box

Quantity/Pallet

36 pcs/pallet or 20 pcs/ pallet

Loading Capacity

504pcs/40ft or 520 pcs/40ft(H)

Dielectric Insulation Voltage

(VDC)

3000 max.

Operating Temperature

()

-40~+85

Dimension(mm)

A×B×C

1650×992×46

Installation Hole(mm)

E×F

941×990

Cable Length(mm)

G

1000
