Home > Products > Full HD Video Conference Camera System > SMTSEC SVC-HD910-U20-K7 2.1 Megapixel 1/2.8" Progressive CMOS 10x Optical ZOOM video conferencing system Camera

SMTSEC SVC-HD910-U20-K7 2.1 Megapixel 1/2.8" Progressive CMOS 10x Optical ZOOM video conferencing system Camera

FOB Price

Negotiable

1 (Min.Order)

Supply Ability 0 per Month

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price

Product Details

Place of Origin:	China	Brand Name:	SMTSEC	Model Number:	SVC-HD910-U20-K7
Type:	Other, Video conference camera

Product Description

SMTSEC SVC-HD910-U20-K7 2.1 Megapixel 1/2.8" Progressive CMOS 10x Optical ZOOM video conferencing system Camera

Product Description

Model		SVC-HD910-U20-K7
Image	Sensor	1/2.8″Progressive CMOS
SenSor	Effective Pixel	2.1 Megapixel
	Min.Illumination	Color: 0.1Lux B/W: 0.01Lux
	White Balance	Auto/Manual
	Gain Control	Auto
	Back Light Compensation	On/Off
	Electronic Shutter	1/1 - 1/10,000S
	SN Ratio	>50db
Lens	Focus	f=4.7-47mm F1.6-3.5
	Iris	Auto/Manual
	Zoom	10 Optical X 12 Digital
	HOV	60.9°- 5.86°
Video Output Interface		USB2.0
Video Output Format		USB2.0:1080P30/25/20/15/10/5,
Video Output Format		720P30,640×480/30/25/20/15/10/5
Control terminal		RS-232C, RS-485,
Control Protocol		VISCA,PELCO-D
baud rate		9600/38400bps
patrol line		4 cruise sequence
preset position		64 preset positions
Speed Match		Pan/Tilt movement speed depends on camera module zoom in/out
OSD Menu		Access to OSD Menu and adjust camera module parameters
Image auto flp		Support
Pan movement speed		1-60°/S
Tilt movement speed		1-60°/S
Pan movement range		355°
Tilt movement range		90°(Up),45°(Down)
Pan scanning automatically		Support Pan scanning automatically
Boundary scanning		0-355°(programmable)
Remote controller		IR Wireless Remote controller P/T/Z
Power supply		DC12V,2A
Work Temperature		0-50℃
Humidity		0-95%RH
LxWxH		145mm×148mm×160mm
Weight		915g

SMTSEC Video conference camera FAQ
Symptom	Cause	Remedy
The power of the camera is not turned on.	The supplied AC power adaptor is not connected to the DC IN 12V jack firmly, or the AC power cord is not inserted firmly into the AC power adaptor or the AC outlet.	Insert the power cord firmly as far as it will go.
The power of the camera is not turned on.	Not Turn On the Power switch as “ON”.	Turn On the Power switch as “ON”.
Insufficient frame rate detected	Cannot recognize USB 3.0 connection, but the USB 2.0 speed.	Make sure you connected USB 3.0 Cable, USB 3.0 connect, and firmly connect to USB 3.0 interface.
Pan,tilt or zoom cannot be operated.	Any menu is displayed on the monitor screen.	Press the “Dome OSD” OR “Lens OSD” on the Camera remote control Unit to turn off the menu from the monitor screen.
Pan,tilt or zoom cannot be operated.	The panning or tilting range is limited	Pan/Tilt movement range is ± 45 degree.
The Remote Commander does not work.	The Camera Select button you pressed on the Remote Commander does not match the number set with the IR SELECT switch on the camera.	Press the Camera Select button corresponding to the IR SELECT SWITCH setting on the Camera.
The Remote Commander does not work.	Used out of battery	Change new battery (AA x 2)
The VISCA control is not available with a computer connected to the camera.	The computer is not correctly connected to the camera.	Make sure the connection between the computer and camera is made correctly.
	The computer is not correctly connected to the camera.	Check that the VISCA control setting (RS-232C or RS-422) and the baud rate setting (9600 bps or 38,400 bps) are properly made with the BOTTOM switch on the bottom of camera and the COM Port which configured in your computer.
The camera cannot be operated at all.		Pull out the plug of the power cord from the AC outlet, then reinsert it into the AC outlet after a while.

Packaging & Shipping

China Post (10-30 days)
EMS (5-15 working days)
DHL (3-5 working days)
UPS (3-5 working days)

•The most reliable, affordable way of shipping method deponds on your address.
•Online tracking number will be emailed to buyer through email.
•We dont take any responsibility for any custom delay.

Our Services

•All products have been checked and packaged in good condition before dispatch.

•All products have 1 year warranty.
