Sun Aging Tester
- 110 Unit / Units per Month
- ShangHai TianJin DaLian ShenZhen GuangZhou HK
- T/T L/C D/P D/A Credit Card PayPal
Product Details
Place of Origin: | Shaanxi, China | Brand Name: | LIB | Model Number: | XL-500 |
Power: | Electronic | Usage: | Other, Sun Aging Tester |
Product Description
Sun Aging Tester
Sun Aging Tester
Main Technical Parameter
Model | XL-500 | XL-750 | XL-S-500 | XL-S-750 |
Internal dimensions mm | 500*760*500 | 950*950*850 | 500*760*500 | 950*950*850 |
Overall dimensions (mm) | 1200*1150*1480 | 1280*1320*1980 | 1200*1150*1480 | 1280*1320*1980 |
Specimen Capacity | 28 | 34 | 28 | 34 |
Holder size | 8*15cm | 8*15cm | 8*15cm | 8*15cm |
Distance between sample and lamp | Approx. 350mm | Approx. 450mm | Approx. 350mm | Approx. 450mm |
Irradiance Ranges W/m2 | 100~1200 W/ 280nm~800nm | 40 ~ 180 W/ 300-420nm | ||
Xenon lamp power | 6500W(Lamp life time: 1600 hours) | 1500(4500)W(Lamp life time: 1600 hours) | ||
Technical structure | ||||
Xenon Arc Lamp | 1 Water Cooled xenon arc lamp with inner quartz and outer borosilicate filter. | |||
Temperature range | Ambient ~100℃ | |||
Relative Humidity range | 50~98% R.H | |||
BPT Temperature | 35 ~85℃ | |||
Water spray time | 1~9999H59M, settable | |||
Water spray cycle | 1~240 minute, interval settable | |||
Control system | ||||
Controller | programmable color display touch screen controller | |||
PC Link with software, R-232 interface | ||||
Temperature Sensor | PTR Platinum Resistance PT100Ω/MV A-class | |||
Temperature Resolution | ± 0.001 ℃ | |||
Humidity Sensor | Dry and wet bulb sensor | |||
Humidity Resolution | ± 1%RH | |||
Radiometer | Tolerance: ±5% | |||
Heating system | Independent Nichrome electronic heating system | |||
Cooling system | French TECUMSEH compressor | |||
Humidification system | External isolation, stainless steel surface evaporation humidifier | |||
Water supply system | Automatic water supply, Water purification system, Water save | |||
Circulatory system | Cold resistance and low noise centrifugal fan | |||
Material | ||||
Exterior material | Steel Plate with protective coating | |||
Interior material | SUS304 stainless steel | |||
Insulation window | Double thermostability silicone rubber sealing | |||
Power Supply | AC380V 50HZ Three-phase five line system | |||
Ambient Temperature | 5℃~+30 ℃ ≤85% RH | |||
Standard | IEC 60068-2-5;JIS D0205; En50483-6; | ISO 105 B02 ;ISO 105 B07; AATCC TM 16; ASTM G 155; |
Test area and sample holder
a)Test area is made of stainless-steel.
b)Standard sample holder.
c)If need special holder, should confirm in advance.
Control panel
a) It is located on the right side of the test chamber
b) Programmable color display touch screen controller
Program: 100 groups in 999 sections
R-232 interface; PC Link with software
Xenon arc lamp
a) Chamber equipped with 1pc of Xenon lamp, which is water cooling.
b) Xenon Lamp Power is 1500W / 4500W / 6000W.
c) Xenon lamp service life is 1600hours.
Long time Services
Warranty: 3 Years
Service:
Our company will repair the product, if the product, the material of the parts, the design and manufacturing of the products made by our company arise hardware problems caused by product itself rather than human error within three years warranty period since the date of delivery. |
Firstly, we can provide the spare parts with you. And provide the solution about the trouble of the products.
Secondly, Please send back the apparatus, which will be repaired by our company.
Lastly, we would like to appoint our technical engineer to your company to repair the apparatus. |
Question: I need chambers very urgently, do you have stock ?
LIB: we have no stock, our standard delivery is 30 days , if you need in urgent , we can speed up the production ,will short to 25 days , customer should notice before order .
Question: How about your LIB payment terms?
LIB: Our payment is 50% with order, and 50% before delivery.
Question: Can LIB arrange delivery to our office (Lab)?
LIB: Yes, LIB can arrange shipping to your country and to your office ( Lab) by sea, by air, by train and by truck on conditions FOB, CFR, CIF, DDU and DDP for customers .
Question: Can we visit your plant before order?
LIB: We welcome and sincerely invite you or your team to visit our plant, we will help you to arrange hotel and pick you up from airport.
Question: Have you sold chambers to our country?
LIB: Now LIB climatic test chambers sold to more than 25 countries, like USA, Canada, Russia, UK, Italy, Germany, European Union, India, Pakistan, Philippines, Singapore, Vietnam, Thailand, Iran, Brazil ……and so on .
Question: Can you arrange installations and commissioning in our lab?
LIB: Firstly, for standard chamber we had 5 days commissioning before shipping , you just need link power in your lab, then can start to operate; Secondly; we had detailed operation manual with chamber , any problems you can find and solve in it; Thirdly, some of customized chambers we should to install and teach your team to operate .
Question: How about your warranty?
LIB: It is three years warranty for every LIB’s chamber, and lifetime service. Now LIB has 8 agents in the world, and in Europe (Italy) , America (USA) Middle East(Iran) had service office, we can in first time to solve your problems.
