Home > Products > Scissor lift > stationary cargo lift/scissor lift for warehouse

stationary cargo lift/scissor lift for warehouse

FOB Price

USD $1,000 - $10,000 / Set

1 Set(Min.Order)

Supply Ability 50 Set / Sets per Month
Port qingdao
Payment Terms:T/T Credit Card

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price

Product Details

Place of Origin:	Shandong, China	Brand Name:	hongty	Model Number:	sjg
Lift Mechanism:	Scissor Lift	Lift Drive / Actuation:	Hydraulic	Power:	3kw
Rated Loading Capacity:	10t	Min. Lifting Height:	0.65m	Max. Lifting Height:	20m
Table Size:	according to the demand	Overall Dimensions:	according to the demand	Certification:	CE
Warranty:	1 year

Product Description

Specifications

1.lifting height:0.1-20m
2.load capacity:0.1-10t
3.CE

Stationary scissor lift

Advantages

Hydraulic lifting system,the far-end control and multi-control points at the different floors could be realized hierarchical control.Stop anywhere at the preconcerted and accurate location point.It can work under any condition,great load capacity,safe and reliable.There are sensitive over load protection devices looking device for failing protection.

Application

It is droved by the electric and hydraulic systerm,,the lift platform is lifted up and drops down along the track;it is installed in the pit or the ground floor to convey the goods from one floor to another and convey the goods from one working level to another.The control panels are available at the designated floors and on the lift platforms.

Loading capacity

Lifting height:1.65-20m;load capacity:0.1ton-150ton(customer-made)

Warranty

12 months from delivery apart from artificial damage.free lifelong technical service.

Specifications

We accept any customer-made specification,hereinafter the parameters only for reference.

SSL series	Load	Platform size	Lifting height	No-work height	Dimension(m)	Pump station
SSL0.8-3.5	0.8T	1.8*1.2m	3.5m	800mm	1.81.20.80	2.2kw\|380v
SSL2-3.5	2T	1.8*1.2m	3.5m	680mm	1.81.20.68	3kw\|380v
SSL2-0.5	2T	1.8*1.2m	0.5m	440mm	1.81.60.44	2.2kw\|380v
SSL1-6	1T	1.9*1.1m	6.0m	1100mm	1.91.101.1	3kw\|380v
SSL2-6	2T	2.0*1.3m	6.0m	1200mm	2.01.31.20	4kw\|380v
SSL1.5-0.8	1.5T	2.0*1.5m	0.8m	500mm	2.01.50.50	3kw\|380v
SSL1-4.3	1T	2.0*1.8m	4.3m	800mm	2.01.80.80	4kw\|380v
SSL2-6	2T	2.0*2.0m	6.0m	1030mm	2.02.01.03	4kw\|380v
SSL3-2.4	3T	2.0*2.0m	2.4m	630mm	2.02.00.63	2.2kw\|380v
SSL3-2.4	3T	2.0*2.0m	2.4m	660mm	2.02.00.66	4kw\|380v
SSL2-5	2T	2.1*1.2m	5.0m	870mm	2.11.20.87	4kw\|380v
SSL1-4.5	1T	2.1*1.5m	4.5m	800mm	2.11.50.80	3kw\|380v
SSL5-6.5	5T	2.2*1.6m	6.5m	1280mm	2.21.61.28	5.5kw\|380v
SSL3-6.5	3T	2.2*1.9m	6.5m	1520mm	2.21.91.52	5.5kw\|380v
SSL1.5-3.8	1.5T	2.2*2.0m	3.8m	700mm	2.22.00.70	4kw\|380v
SSL2-3.8	2T	2.2*2.0m	3.8m	830mm	2.22.00.83	4kw\|380v
SSL2-5	2T	2.3*1.4m	5.0m	870mm	2.31.40.87	4kw\|380v
SSL2-5.15	2T	2.3*1.4m	5.1m	870mm	2.31.40.87	4kw\|380v
SSL 2-1.3	2T	2.3*2.0m	1.3m	400mm	2.32.00.40	2.2kw\|380v
SSL **-N	Customer-made according to the requirement
