keel roll forming machine

FOB Price

USD $8,000 - $18,000 / Set

1 Set(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Type	Tile Forming Machine
Tile Type	Steel	Use	Other
Production Capacity	45m/min	Place of Origin	Hebei, China
Brand Name	huachen	Model Number	HC67*70
Power(W)	5.5+3kw	Voltage	380V 50Hz 3phases
Dimension(LWH)	4400750900mm	Weight	2.5T
Certification	CE/ISO9001	Warranty	1 Year
After-sales Service Provided	Engineers available to service machinery overseas

1. Equipment Detailed Parameters:

No
1	Suitable Material	Colored Steel plate, Galvanized Board,Aluminum Plate
2	Width of the raw material	120mm
3	Rows of rollers	10 rows
4	Appearance size	44007509000mm
5	Total power	Main motor power -5.5kw Hydraulic station power-3kw
6	Thickness of raw material	0.4-0.5mm
7	Productivity	45m/min
8	Diameter of shaft	40mm
9	Voltage	380V 50Hz 3phases

Components

Specification of Components:

No		Technical Specification
1	Manual Uncoiler	Usage:It is used to support the steel coil and uncoil it in a turnable way. The steel coil is uncoiled by hand. Loading capacity:1200KG The max. coil width 200mm
2	Main Roll Forming Machine	Material of rollers:CR12 The polished surface and the heat treatment towards the molds also can keep the molding plate surface smooth and not easy to be marked when it is being stamped.
3	Hydraulic System	Hydraulic Servo Tracking Cutting off, Power 3kw Servo motor power 2kw(Delta)
4	Computer Control Cabinet	All servo PLC touch screen control system (Delta products)
5	Shearing Mechanism	It adopts the hydraulic drive and automatic location to decide the dimension and cut the target products. Material of blades: Cr12,quenching treatment
