Good Quality and After Sale Service Transformer Oil Test Equipment

Good Quality and After Sale Service Transformer Oil Test Equipment

Good Quality and After Sale Service Transformer Oil Test Equipment  is apply to test the insulating oil's dielectric strength, which is designed as per the requirement of IEC165 Testing Method of Insulation Oil Medium Strength, which via proper programming, has got functions of auto boosting, step down, stirring, display and print out. After breakdown of oil medium, HV break off will operate within 10 seconds to enable an auto isolation of control system partly; this effectively safeguards the personnel security and equipment safety.

Features:

Transformer Oil Test Equipment adopt industrial SCM to control which is applied to integrate circuit, new model  I/0 connection , particular testing and anti-jamming technology which is largely improved the machine's capacity .

Transformer Oil Test Equipment  Main features:

1.    Simply operate: automatically (can be finished just press on key)

2.    Menu controlled. Input data can clear

3.     Can store 99 groups’ oil testing data which is convenient to reading and print. The testing data can keep 100 years under the condition of power off.

4.     System time can go on running under power off; (The system time just for reference can not be the standard of timing)

5.    Can upgrade software through RS232

6.    High capacity of anti-jamming and high precision of testing.

7.    Small volume, light which operated in the open air very conveniently.

Transformer Oil Test Equipment Technology and parameter data

1. Working power supply: AC220V ± 10%, 50HZ ± 5%
2.  Measuring range: AC 0-80KV
3. limit the current: 5mA
4. Measurement accuracy: 1%
5. Regulator speed: 2KV / S ± 10%
6. pre-set: the number of 1-9
7. Mixing time : 0 to 1 minutes and 39 seconds
   Standing time: 0 to 10 minutes and 39 second
8. conditions: ambient temperature 0 °C -35 °C
9.  Relative humidity ≤ 75%
10. oil cup clearance: 2.5mm (oil cup plug-foot diameter)
11. Dimensions: 415 × 315 × 315mm3
12. 10.Weight: 28kg

YUNENG SYS-3 Transformer oil dielectric strength testing kit from Chongqing Yuneng OIl-Filter Manufacturing Co.,LTD
