High frequency 2000W AIMS Off grid solar micro inverter ac drives with charger wholesale

FOB Price

USD $96 - $100 / Piece

50 Pieces(Min.Order)

Supply Ability 50000 Piece / Pieces per Month
Port Xiamen
Payment Terms:T/T Credit Card PayPal

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price

Product Details

Place of Origin:	Jiangxi, China	Brand Name:	MFW	Model Number:	PW-2000
Output Power:	201 - 400KW	Output Type:	Single	Size:	550210145
Weight:	4.4KG	Input Voltage:	12/24/48/110vdc	Output Voltage:	100/110/220vac / 220/230/240vac
Type:	DC/AC Inverters	Output Frequency:	50/60Hz±3	Output Current:	5-10A

Product Description

High frequency 2000W AIMS Off grid solar dc inverter with charge wholesale alibaba

Product Description

High frequency 2000W AIMS Off grid solar micro inverter ac drives with charger wholesale alibaba

PRODUCT SHOW

Parameter Table

Rated Power	2000W
Peak Power	4000W
Output Voltage	110V	230V	110V	230V	110V	230V
Frequency	50/60Hz3
USB Port	5V,500mA(Optional)
Output Waveform	Pure Sine Wave
Protection Function	Bat.Low Voltage Alarm&Shut Down,OverLoad,Over Temperature,OverVoltage,ShortCicuit,Reverse Polarity
Input Voltage	12V		24V		48V
Dimension	550210145mm(LWH)
N.M./unit	9750g
QTY/Ctn	6Pcs
Packing	Gift box
Meas./Ctn	68.53533.5cm
Warranty	18 Months

2.Features

High Surge: high surge current capability starts difficult loads such as TVs, camps, motors and other inductive loads,
Earth Fault Protection: The unit shutdown when the load has electric leakage.
Soft start : smooth start-up of the appliances.
Pure sine wave output waveform: clean power for sensitive loads.
AC output identical to, and in some cases better than the power supplied by your utility
Cooling fan in the inverter is thermally activated and comes on when the inverters becomes warm, and turns off automatically after the inverter has cooled.
Low total harmonic distortion: below 3%

3.Protection functions

Low voltage alarm & Shutdown
Over voltage protection
Overload protection
Over temperature protection
Short circuit protection
Reverse Polarity protection
Soft start
Auto. reset after being in protected
Earth leakage protection

4.Applicable For:

Power tools series: Electric Saw, Drill, Grinder, Sand blast machine, Punching machine, Air compressor etc
Office series: Computer, Printer, LCD monitor, Scanner etc
Household appliance series: Dust collector, Fan, Lighting, Sewing machine, TV, DVD player, Radio etc
Kitchen appliance series: Microwave oven, Fridge, Freezer, Coffeemaker, Blander etc

Packaging & Shipping

Packing :

Every inverter packaging is contained necessary accessories in the same box. 2. The inverter is protected by the shaped foam, in case of the shape and hit in the process of transportation. 3. After packed by cardboard carton, we will sealed the carton by plastic film, in case of the humidity. 4. Finally, we will use packing belt to fix it.

Shipping :

7-10 working days

1.We will ship item to worldwide by DHL, FEDEX,TNT,UPS,EMS,AIR,SEA.

2.Item will be shipped out within 3 business days after cleared payment being received. After we deliver goods, we will give you tracking number.

3.Please leave us your phone number after payment and double check your shipping address,that is very helpful for shipping.

4.In order to ensure you receive you order tax free upon import, we will declare it as a 'GIFT' with a lower value. This lower price does not reflect the total price you paid or the market value of the product and may not apply to countries with different tariff rules. Any import charges or fees are the buyer's responsibility.

Company Information

Mingwei Electronic Corporation, founded in 2003,is recognized as the leading manufacturer of industrial switching powelies in China. Our self-invested new factory is located in Jiangxi Ruijin, covering an area of 21000m²,factory building 20000m².The products include AC/DC&DC/DC standard, PFC, open frame, battary charger, din rail, LED driver and custom-design switching power supplies, over 5000 models showing greating flexibility. “Mingwei” has been a famous brand in China, and incresingly well-known in world market.

OUR COMPANY

workshop

FAQ

1. What are the difference between pure sine wave inverter and modified sine wave inverter?

A: The output waveform of pure sine wave inverter is as well as, even better than the 220v 50/60Hz electricity, which suitable for all electrical appliances, such as motor, refrigerator, compressor, washing machine, air conditioner etc. in addition, the pure sine wave inverter can supply stable and high quality AC with low EMI (electromagnetic interference), low noise, low THD (total harmonic distortion, less than 3%), it won’t affect the performance and life of load.

The modified sine wave inverter needs lower cost and technology, so it is cheaper .but it can’t load high power inductive load, such as motor, compressor, refrigerator, air conditioner. What’s more, the modified sine wave inverter will make the EMI for the precision equipments and communication equipments. And the THD ≤20%.
