55hp Compact Tractor Brands

                                               Model

SH554

                                                       Engine

Engine Power KW/HP

40.44kw / 55hp

Engine Type (CLD, T/NA)

4 ,Turbo charger /Natural Aspirated

Rated Speed (rpm)

2200

Engine Torque (NM @ engine rpm)

255~260,≤1650

Specific Fuel Consumption (L/h)

≤12.7

Emission Regulation availability (Euro I,II,II)

stageⅡ

Cooling type

Water cooling

Engine Displacement(L)

4.156

Air filter type

Oil Bath

Fuel tank capacity (L)

78

Exhaust pipe (Vertical/Horizontal)

Vertical

Engine starter (kw)

3.8

Alternator (V/w)

14V/500

                                                  TRANSMISSION

Type of clutch

Single, Dry

Total gears

12F + 12 R

Synchronized Gearbox (YES/NO)

NO

Min-Max speed

3.04-34.71 F / 3.44-14.76R

Differential lock (limited slip/100% lock)

100% lock

Max Draw bar Pull 2WD/4WD (KN)

16.5/18.75

Type of rear final drive (Planetary, cascade),

Planetary/4

                                                        PTO

PTO speeds PT(rpm)

760

PTO speed @ engine speed

760/2200

PTO engagement

8XΦ38/6XΦ35/21XΦ35

PTO independent clutch (YES/NO)

YES

PTO shaft splines

6 or 8

                                                HYDRAULIC SYSTEM

Outlets pump type

gear pump

Max pressure (bar)

160

Max pump delivery @ engine rpm(ml/r),(rpm)

16/2000

Outlets valves function

Float

                                              TECHNICAL DATA

Overall size 2WD (L*W*H) / mm

4090x1914x2719

Max height with ROPS / mm

2585

Max height with CABIN / mm

2700

Rear Wheel track 2WD / mm

1430-1830

Front Wheel track 2WD / mm

1400-1700

Rear Wheel track 4WD / mm

1430-1830

Front Wheel track 4WD / mm

1450
