12V 24V 36V 48v 96V lithium ion battery pack for electric scooter,electric car,HEV,UPS,Energy Storage

Specifications

12V 24V 36V 48v 96V lithium ion battery pack for electric scooter,electric car
1,48v 50ah lifepo4 battery pack for ev
2,safe



Material system ( included LFP/ LMO/ NMC/ LTO ) ,dimension ,capacity and performance parameter can be customized.

Model No.	48V50AH	Standard Charging current	0.2C
Weight	≤28kg	Standard Discharging current	0.2C
Nominal capacity	50Ah	Fast Charging current	1C
Nominal voltage	48V	Maximum discharging current	3C
Internal resistance	≤70mΩ	Max. Charge/discharge pulse current(10S)	8C
Energy density	≥100Wh/kg 0.2DCD	Charging Temperature	0~45°C
Discharge cut-off voltage	32V	Discharging Temperature	-20~55°C
Charge voltage	58V	Cycle Life	2000 times



We are the unique  golf  cart battery manufacturer in China  of highcapactiy cylindrical battery 10-100AH for cell!!! diffrent types of battery series which contain LFP, LMO ,NMC, LTO .We can customizeproducts according to your performance parameters.



The most reasonable structure decides the  future of power battery!!!



 Product Characteristics:



•  Winding structure ,natural close fit,strong seismic resistance.
•  Zero dust, zero burr, to eliminate safety hidden trouble from source
• Super performance in rate discharging (pulse current reaches 1000A)
• 360 degree in any display, high space utilization
• Long cycle life ,super cell consistency




  Features:

  1. Good cell consistency, High energy density.

  2. Low internal resistance, low thermal generated and high safety performance.

  3. Good high temperature performance.

  4. High capacity, low self-discharge rate and long cycle life.

  5. Dimension and type(capacity type and ratio type) can be customized.



  Applications:

  1. EV: pure electric car, pure electric bus, hybrid electric vehicles, hybrid electric bus, recreational vehicles, chill cars.

  2. Storage: solar and wind complementary stored energy streetlights, energy storage systems, household energy storage.

  3. Power Supply: communication base station power supply, utility power supply, communication industry, emergency power supply and other system standby power etc.
