15Kvar-60Kvar, Reactance Rate 7%/14% TSC Silicon-controlled Electric Switch Buy Direct Factory

TSC Silicon-controlled Switch

Silicon-controlled switch is Bocheng launched a new generation of independent research and development, adopting high speed CPU control, pulse transformer high reliable trigger, with multiple monitoring protection scheme (current, temperature, lack of phase, the breakdown of real-time monitoring and protecting) and fast switching technology new products. Regardless of the residual voltage of the capacitor for any value, can achieve capacitor branch in real time, without the impact of input and response time for 0-15 msec, instead of the best products of AC contactor and composite switch.

Specification

Rated voltage：230V~800V, 50/60Hz

Rated power：15Kvar-60Kvar, reactance rate of series connected 7%/14%

can be chosen

Temperature range：-20°C~60°C

Overload capacity：1.5time In next minute

Altitude：<4000M

Humility：95%（relative humility）

Use place：any place,dust proof and moistureproof

Standard:IEC60439，IEC146

Noncontacting Silicon-controlled Switch,product advantage

1,Real time fast switching, repeated investment time is less than 15ms;

2,Independent research and development, high frequency pulse trigger, stable and reliable;

3,Using imported silicon control module, the overall service life is long;

4,With current, temperature detection and display function;

5,With the functions of intelligent over current protection, temperature protection, phase lack protection and controlled silicon breakdown protection, alarm and so on.

6,According to the fault type, it can be given different status indication, which is convenient for trouble shooting.

7,It can be single phase, phase compensation and three-phase compensation, to adapt to different applications

8,Capacitor without discharge, regardless of whether the residual voltage of the capacitor is numerical, capacitor circuits can achieve real-time, no shock to investment, zero current off, no inrush current.
