Specifications
Work faster and higher accuracyWater cooling system
Semiconductor module
Features
1.The X.Y axis adopt imported linear guide rail and imported servo motor with speed-reducing driving system to make cutting stable and cutting surface smooth.
2.Double water-cooling system with self-protective function assures stable continuous running.
3.We offer two laser tube and two laser head for each equipment which can improve efficiency of the equipment.
4.Supports all kinds CAD professional drawing software,avoide the trouble of exchanging graphs.
5.The warming cooling case ensure that the machine works safely.
6.Special aluminum table reduces the damage to materials by reflected light.
7.Large memory capacity &possible offline work.
Technical Parameters
Laser Generator | Hermetic and detached CO2 laser tube |
Laser Power | 60w /80w |
Work area | 600*400mm |
Positioning Precision | ±0.01mm |
Cooling Mode | Circulating-water-cooling |
Machine Control and Drive | Speedy DSP controlling, stepper motor |
Power Adjustment | 0-100% controlling, no segment and adjusting by software |
Controlling Software Language | English, Simplified Chinese, Traditional Chinese and procuring of multi-languages |
Machine Color | grey/Red , Orange/Grey |
Minimum Character | Chinese character 1.5mm, crisscross-row 1mm |
Max Power | ≤1200w |
Up-down Range of Working Table | 50mm |
Optional Equipment | Rotary attachment |
Engraving Speed | 1200mm/s |
Cutting Speed | 600mm/s |
Interface | LCD Screen and USB interface |
Working Voltage | AC220V ±10%,50Hz |
Running Environment | 0-45°, Humidity: 5%-95% |
...
