Home > Manufacturing & Processing Machinery > Laser Equipment > Laser Engraving Machine > Acrylic Wood Laser Engraving Machine With Low Price

Acrylic Wood Laser Engraving Machine With Low Price

Acrylic Wood Laser Engraving Machine With Low Price photo-1
US$ 1,500 - 2,500 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Laser Type:
CO2
Engraving Area:
500*300mm
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao or Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Laser Type CO2
Engraving Area 500*300mm
Engraving Speed 1000mm/s
CNC or Not Yes
Cooling Mode Water Cooling
Applicable Material Acrylic, Crytal, Glass, Leather, MDF, Paper, plastic, Plexiglax, Plywood, Rubber, Stone, Wood
Graphic Format Supported AI, PLT, DXF, BMP, DST, DWG, LAS, DXP
Place of Origin Shandong, China
Brand Name DOWELL
Model Number DW5030
Dimension(L*W*H) 1270*820*600mm
Certification CE, ISO, GS, SGS, UL, CCC
After-sales Service Provided Engineers available to service machinery overseas

Specifications

acrylic wood Laser Engraving machine with low price
1.DSP off-line control system
2.High speed&precision
3.Up&down platform

                                                                                                                           acrylic wood Laser Engraving machine with low price

 Product feature:



1.Choose imported HIWIN square guide from Taiwan,high positioning accuracy and less wear to maintain precision.



2. Adopt high specialized laser tube with stable performance and long life, the facula is of high quality.



3. Input the American imported focusing lens and mental condensing lens, the cutting strength is high.



4. Have a fixed industrial water cooling system for protection to ensure continuous work.



5. Motorized up and down platform, be applicable for different materials.



Product Parameter :


Machine Performance:

Laser-type

Hermetic and detached CO2 laser tube

Laser-power

40w/60w

Cooling Mode

Circulating-water-cooling

Power Adjustment

0-100% controlling, no segment and adjusting by software

Machine Control and Drive

Speedy DSP controlling, stepper motor

Max Engraving Speed

1000mm/s

Max Cutting Speed

500mm/s

Repeating Location

±0.01mm

Minimum Character

Chinese character 1.5mm, crisscross-row 1mm

Max Power

<1500W

Adjustable Up-down Distance of Laser Head

30mm

Working Travel Area(mm)

500*300

Table Area

as the machine

Up-down Range of Working Table

Mechanical 150mm-360mm

Working Voltage

AC110V-220V 50Hz-60Hz

Working Environment

Temperature: 0-45, Humidity: 5%-95%, and congeal-water removed

Controlling Software Language

English, Simplified Chinese, Traditional Chinese and procuring of multi-languages

Dictate Format

*.plt,*.dst,*.dxf,*.bmp,*.dwg,*.al,*las, Support AutoCAD,CoreDraw direct outputting

Packaging

Wooden box

Machine Color

grey/white grey/red white/grey white/black

Delivery Time

5-7  working days

Payment

T/T, escrow

Optional Equipment

Rotary attachment



Motorized up-down table



Water-cooling Chiller



Red-light position



Vacuum table



Auto-focus



Applicable materials:
 Wood, bamboo, jade, ceramic, textile, garments, crystal, plastic, Color plates, plexiglass, glass, acrylic, wood, paper, leather, cloth, rubber, marble, granite, tiles, shells and other non-metallic materials.
Applicable industries:

 Advertisement,arts and crafts,toys,garments,model,building upholster,

computerized embroidery,clipping,packing and paper industry,etc.

Samples:



Certificate:

 acrylic wood Laser Engraving machine with low price





 Jinan Dowell Photoelectricity Equipment Co.,Ltd with 12years production experience,specialized in laser cutting,engraving,marking equipment production,developing and sales and provide customers with comprehensive solutions,compare to same industry,we hold less autonomy R& D companies.



....
