TEC B-SX600 600dpi Thermal Swing Ticket Printer

Standard
HS11-QM-R(USB)
HS12-QM-R(LAN)

Cutter
HC11-QM-R(USB)
HC12-QM-R(LAN)

Peel-off
HH11-QM-R(USB)
HH12-QM-R(LAN)

Technology:

Thermal transfer / Direct thermal

Print Head:

Edge type

Resolution:

600 dpi (23.6 dots / mm)

Print Width:

Maximum 104 mm

Print Length:

3mm to 1000mm

8mm to 1000mm

10mm to 1000mm

Print Speed:

Up to 150 mm/s (maximum).
Available print speed depends on the media and ribbon used and print pattern. The maximum print speed for peel-off is 100 mm/s.

Alignment:

Centered

Media Backing Paper Width:

15mm to 120mm
The maximum print width in thermal transfer mode is 110 mm.

Label Thickness:

0.05 mm to 0.1 mm (liner not included)

Tag Thickness:

0.15 mm to 0.26 mm

0.05 mm or more
(backing paper not included)

Media Shape:

Roll paper (both roll directions acceptable) / Fanfold paper

Outer Media Roll Diameter:

200 mm (maximum)

Inner Media Roll Diameter:

76.2 mm

Ribbon Width:

30 mm to 120 mm

Ribbon Inner Core Size:

25.4 mm to 26.4 mm

Ribbon Outer Diameter:

70 mm maximum (ribbon length: approx. 300 m or less)

Interface:

USB 2.0 Highspeed or LAN 10/100Mbits

Printer driver:

Windows® XP / 2000 / Server 2003

Protocol:

TCP/IP, LPR, Raw (9100)

Options:

Power Cord, Printer Driver and Cleaning Cloth

Operating Temperature /Humidity:

5 to 40 °C (10 to 90 % RH)
Operating temperature and humidity at which print quality
is guaranteed is 18 to 28 °C (40 to 60 % RH).

Input Voltage:

AC 100 to 240 V, 50 / 60 Hz with universal power supply

Power consumption:

250 W or less (when printing)

Dimensions:

300 (W) x 455 (D) x 353.5 (H) mm

Weight:

20.6kg (USB) / 21kg (LAN)
(both without media and ribbon)
