Product Details
| Place of Origin: | Guangdong, China | Brand Name: | AUTOSTRONG | Model Number: | AUTO-SPA |
| Power: | Electronic | Usage: | Other, Plastic Testing Machine, Testing the fireproof performance of cable and wire |
Packaging Details
Packed with wooden case
Product Description
Supplier IEC60332-1-1 vertical flammability tester for cable and insulated wire
Introcution:
Vertical flammability tester for cable and wire is designed according to the relevant standard requirements of IEC60332-1-1 and IEC60332-1-2.
The Vertical flammability tester for cable and wire is composed by the test part and control part, using the integrated design, to facilitate the installation at the scene and debug.
The shell of the test chamber and the important components are all manufactured by stainless steel,resistant cigarettes and gas corrosion; The automatic degree of control system is high, has automatic ignition function, temperature and time figures show, so that the observation and records are facilitate and the use of it is stable and reliable
Technical parameters:
Flame standard | IEC60695-11-2,1kw nominal pre-mixed flame |
Burner Tube | IEC60695-11-2 Figure A |
Burning Angle | 45° |
Thermocouple | Type K (Ni/Cr - Ni/Al),200°~1050° |
Thermocouple Size O/D | 0.5mm |
Temperature Resolution | 1ºC |
Standard Copper Block | weight 10 ± 0 .05 g before drilling. Cu-ETP |
Gas Supply | Propane,min.95% purity |
Input Power | 220 V 50 Hz 3A or 115 V 60HZ Optional |
Inner Dimensions | W*D*H=300mm*450mm*1200mm |
Conform to standard | IEC60332-1-1,IEC60332-1-2,IEC60695-11-2 |
