5mm Glass sheet

Specifications

Float clear glass
1.More choices for thickness
2.Special dimensions as 3300x14000mm
3.Offer a high visible light transmitance

Float glass  is a term for perfectly flat, clear glass (basic product). The term "float" glass derives from the production method, introduced in the UK by Sir Alastair Pilkington in the late 1950's, by which 90% of today's flat glass is manufactured.



Production: The raw materials (silica sand, calcium, oxide, soda and magnesium) are properly weighted and mixed and then introduced into a furnace where they are melted at 1500° C. The molten glass then flows from the glass furnace into a bath of molten tin in a continuous ribbon. The glass, which is highly viscous, and the tin, which is very fluid, do not mix and the contact surface between these two materials is perfectly flat. When it leaves the bath of molten tin the glass has cooled down sufficiently to pass to an annealing chamber called a lehr. Here it is cooled at controlled temperatures, until it is essentially at room temperature.







Float clear glass is made of molten glass which flows through tweel to tin bath and then to lehr. While floating through the molten tin, the glass under the works of gravity and surface tension becomes smooth and flat at both sides. Float clear glass is transparent and offers a high visible light transmittance.  Clear float is sold as cut-to-size or bulk form.  Clear float is also available in laminated,tempered and insulated form.



Features:



Smooth and flat surface and good vision.

Flexible size specifications minimizing cutting loss.

Substrata for each level of glass processing.

Kindly glass offers a complete range of clear float glass products.



Applications:

Table top



Door windows



Double glazed window



Furniture and decoration



Superior performance to standard glass products



 Packing List:

mm	Color	Dimension & Packing
		Width	Length	Pcs/Crate	Crates/20'fcl	Sqm/20'fcl	G.W
2	float clear	1800	2032	110	12	4828.03	24500
3	float clear	1830	2440	67	11	3290.85	25011
4	float clear	1650	2200	68	10	2468.40	24984
5	float clear	2134	3300	27	10	1901.39	24067
6	float clear	2134	3300	23	10	1619.71	24596
8	float clear	2134	3300	17	10	1197.17	24243
10	float clear	2134	3660	12	10	937.25	23731
12	float clear	2134	3660	10	10	781.04	23731
15	float clear	2134	3660	9	10	702.94	26660
19	float clear	2134	3660	7	10	546.73	26270
