Stainless Steel differential pressure indicator

Name: Stainless Steel differential pressure indicator
Brand: YunYi
Availability: InStock

FOB Price

USD $180 - $500 / Unit

1 Unit(Min.Order)

Supply Ability 1000 Piece / Pieces per Month
Port Tianjin
Payment Terms:L/C D/P D/A Credit Card PayPal

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price

Product Details

Place of Origin:

Shaanxi, China

Brand Name:

YunYi

Model Number:

CYW-152B/CYW-153B

Packaging Details

Stainless Steel differential pressure indicator
export packing

Product Description

Stainless Steel differential pressure indicator

Product Overviews

Description:

YW-152B and CYW153B stainless steel differential pressure gauge (hereinafter referred to as instrumentation) applicable in the measurement of various liquid (gas) medium differential pressure, flow and other parameters of process chemicals, chemical brazing, metallurgy, electric power, nuclear power and other industrial sectors. All meter structure made of stainless steel, which is the measurement system (dual bellows urgent connecting parts), pressure systems (including joints, pipes, etc.) using reasonable special structure design, advanced technology, with small size, light weight, good stability , long life, the appearance of new, strong adaptability advantages. Connection Meter joints are parallel (can be directly connected with the three valves) and two inclined, able to adapt to different customers supporting the installation.

Technical data:

1 Ambient temperature:. -40 ~ 70 °C

2 Anti-vibration environment:. V.H.3 level

3 Weight: about 1.5kg

4 meter shell protection grade:. IP54

5 Differential pressure measuring range nominal working pressure, accuracy levels and joint thread size;

range		nominal working pressure		accuracy degree	Joint thread sizes
0~10 0~16 0~25 0~40 0~60 0~100	KPa	60 100 160 250 400 600	KPa	2.5	M20x1.5 NPT 1/2
0~0.16 0~0.25 0~0.4 0~0.6 0~1 0~1.6 0~2.5	MPa	1 1.6 2.5 4 6 10 10	MPa	2.5	M20x1.5 NPT 1/2

Detailed Images

Company Profile

Xi'an Yunyi Instrument Co., Ltd.

Xian Yunyi Instrument Co., Ltd. is a professional manufacturer that engaged in the fields of pressure measurement instrument, the chief engineer, Mr Tian has more than 30 years experience on this area, and he is one of the engineers who introduced the Rosemount technology.

We are specialized in developing pressure transmitter, etc. They are widely used in chemical, petroleum, paper, electricity, city gas, environmental protection, water treatment and other fields.
