Home > Products > Powered by Deutz > DEUTZ diesel generator 90KVA
DEUTZ diesel generator 90KVA
USD $4,000 - $15,000
/ Piece
1 Piece(Min.Order)
- 300 Piece / Pieces per Month
- Fuzhou
- T/T L/C D/P D/A
You May Like
Product Details
| Place of Origin: | Fujian, China | Brand Name: | BOBIG | Model Number: | BDA100S |
| Output Type: | AC Three Phase | Speed: | 1500/1800rmp | Frequency: | 50/60 |
| Rated Power: | 72KW | Rated Voltage: | 400,415,440/220V | Rated Current: | 90KVA |
Product Description
Specifications
DEUTZ diesel generator 90KVA1. Air cooled
2. Copy stamford alternator
3. Brushless excitation
4. ISO9001&CE
DEUTZ diesel generator 90KVA
| BOBIG-DEUTZ FL912/913 SERIES DIESEL GENERATING SET | ||||||||
| Model | GF2-12 | GF2-20 | GF2-24 | GF2-30 | GF2-36 | GF2-40 | GF2-50 | |
| Engine Model | F2L912 | F3L912 | F4L912 | F4913 | F4L912T | F6L912 | F6L912T | |
| Engine Continue Power(KW) | 1500rpm | 14 | 24 | 32 | 34 | 41 | 48 | 61 |
| 1800rpm | 17 | 28 | 38 | 40 | 48 | 55 | 72 | |
| Combustion System | Direct injection | |||||||
| Cycle | Vertical 4-Stroke ari-cooled direct injection | |||||||
| Governing method | Machine Governor | 5% | 5% | 5% | 5% | 5% | 5% | 5% |
| Electronic Governor | 1% | 1% | 1% | 1% | 1% | 1% | 1% | |
| Intaking method | Natural apirated | Turbo charging | Natural apirated | Turbo charging | ||||
| Cylinder numbers | 2 | 3 | 4 | 4 | 6 | 6 | 6 | |
| Bore/stroke(mm) | 10/120 | 100/120 | 100/120 | 102/125 | 100/120 | 100/120 | 100/120 | |
| Displacement(L) | 1.88 | 2.828 | 3.77 | 4.085 | 3.77 | 5.655 | 5.655 | |
| Compression ratio | 17 | 17 | 17 | 17 | 17 | 17 | 17 | |
| Engine Maximum Power(KW) | 1500RPM | 16 | 26 | 35 | 37 | 45 | 52 | 66 |
| 1800RPM | 19 | 30 | 42 | 44 | 52 | 62 | 78 | |
| Crankshaft rotation direction | Counterclockwise(face to output end) | |||||||
| Fuel consumption(g/kw.h) | 1500rpm | 238 | 230 | 228 | 238 | 218 | 228 | 228 |
| 1800rpm | 238 | 232 | 230 | 248 | 220 | 228 | 230 | |
| Generator Power(KW) | Prime(continue | 12 | 20 | 24 | 30 | 36 | 40 | 50 |
| Standby(Maximum) | 14 | 22 | 28 | 34 | 40 | 44 | 55 | |
| Lubrication System Capacity(L) | 8 | 11 | 12 | 12 | 12 | 14 | 14 | |
| Lubrication Oil Consumption | 1% | |||||||
| Combustion Air Flow (m3/min) | 1.42 | 2.12 | 2.83 | 3.12 | 3.61 | 4.24 | 5.19 | |
| Exhaust Gas Flow(m3/min) | 1.46 | 2.18 | 2.91 | 3.2 | 3.71 | 4.37 | 5.45 | |
| Exhaust Gas Temperature() | 500 | 500 | 500 | 500 | 550 | 500 | 550 | |
| Area of Heat Dissipation() | 0.08 | 0.12 | 0.16 | 0.16 | 0.16 | 0.24 | 0.24 | |
| Electric system | 12V/24V | |||||||
| Net Weight(kg) | 480 | 680 | 750 | 780 | 880 | 920 | 1150 | |
| Packing Size LWH(cm) | 130*80*110 | 170*80*125 | 180*80*125 | 180*80*125 | 185 | |||
