Professional A4 Paper Making Machine Manufacturer, Notebook Paper Machine factory
- 0 per Month
- Qingdao Port China
- T/T Credit Card
You May Like
-
Writing and printing paper Machine/Cultural Paper Machine
-
wholesale bulk , 1880mm office copy paper/ cultural paper making machinery, newspaper printing production from Qinyang FRDS
-
Large output 2400mm Culture Paper Machines, 2400mm Waste Paper Pulp Paper Making Machine / Whole Culture Paper Production Line
-
Qinyang FRDS 2400mm Culture Paper Machines, 2400mm Waste Paper Pulp Paper Making Machine / Whole Culture Paper Production Line
-
Paper pulp making machine/waste paper as material pulp machine
-
Waste paper pulper machine / paper pulper machine/ pulp machine
Product Details
| Type | Other | Computerized | Other | |
| Place of Origin | Henan, China | Brand Name | FRD | |
| Certification | CE | Warranty | I year | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Standard wooden case
Product Description
Professional A4 Paper Making Machine Manufacturer, Notebook Paper Machine factory
A4 Paper Making Machine:
Our company can produce all kinds of paper making machine, including office paper machine, copy paper machine, printing paper machine,writing paper machine and A4, A3 paper machine.
I.Technical parameters of A4 Paper Making Machine:
Raw material : White office paper, wood pulp or wheat straw
Output paper : printing paper, copy paper, writing paper, A4 paper and office paper;
Gram weight: 60-90gsm
Working speed : 60-150m/min
Width of cylinder mould: 2600mm
Rail gauge: 2800mm
Drive way: sectional drive, Alternating current frequency conversion adjustable speed.
II. Main frame of Equipments on the A4 Paper Making Machine:
Part name | Equipment | Specification | Qty(set) |
Mesh cylinder part | Cylinder mould | Φ1500mm×2400mm | 3 |
| Net slot | 12 thick polyethylene plastic sheet welding | 3 |
| Couch roll | Φ450mm×2400mm | 1 |
| Reverse roll | Φ450mm×2400mm | 1 |
Press part | Stone roll | Φ650mm×2400mm | 1 |
| rubber roll | 600mm×2400mm | 1 |
| Pneumatic loaded device | ||
Dryer part | Dry can | Φ2500mm×2400mm | 2 |
| Dry can | Φ1500mm×2400mm | 3 |
| Touch roll | Φ650mm×2400mm | 1 |
| Pneumatic loaded device, shore hardness is 90o±2, second and third cylinder part are equipped with dry wire. & anti-pressure device | ||
Designed type | Rack is square box, cast iron, All-pneumatic pressure | ||
Drive | Reduction box, coupling, adjustable speed | ||
Different types of our A4 paper making machine:
Model | 1575 | 1760 | 2200 | 2500 | 2800 |
Max.parent roll width(mm) | 1750 | 2000 | 2150 | 2400 | 2700 |
Max.parent roll diameter | Standard diameter1100mm unless otherwise specified | ||||
Qty of unwind stand | 3 stands (pls specify when order) | ||||
Core inner dia.of parent roll | Standarddiameter3”(76.2mm) unless otherwise specified | ||||
Data setting | HMI | ||||
Programming controller | PLC | ||||
Operate speed | 0-160m/min | ||||
Outer dia.of finished log | Diameter90-135mm | ||||
Core inner dia.of finished log | Diameter25-50m | ||||
Diameter of finished log control | Electronic/Air control | ||||
Mechanical driving | Driving by Stepless gear box | ||||
Air -system | 3HP air compressor, min. pressure 5kg/cm2pa ( provide by user) | ||||
Main driving | Frequency conversion speed regulation 9KW 380V,50HZ | ||||
Embossing unit | Two sets steel to rubber | ||||
Dimensions | 6x3x1.7 (length x width x height);(m) | ||||
Weight | 3T | ||||
The company mainly produces pulping equipment,paper making equipment,clean pulping equipment and environmental protection equipment four categories,more than 60 series and more than 200 kinds of products,sixteen kinds of products obtained national patent.
Companies adhere to the “industrial science and technology innovation as the driving force,and constantly develop new products to energy saving and high efficiency,high technology and services to customers,with superior product quality to win the trust of customers.Friends has the right to import and export,the products are sold through out the country and exported to Vietnam,Thailand,India,Indonesia,South Africa,Syria,USA,Middle East,Russia and other countries,in the international market has formed a good corporate image and product brand.
Sustainable development of an enterprise depends on the brand,the effective maintenance and continuation of business.Unified,strong and Implicit profound brand culture,is the foundation and the power enterprises’ growth.There is no culture,enterprises can only stop stay in the shallow level of penny earn,never popular.Erect a banner to the enterprise culture.Pointed out the direction,highlight the core with goal of strengthening the management of Enterprises,from building the unique spirit of enterprise system start.
Companies adhere to the “industrial science and technology innovation as the driving force,and constantly develop
Turn-key engineering service
Complete project design
Lubrication system & Hydraulic system
Stock preparation system design
QCS system & Steam condensate system
Approach system design
Automation control system(MSC)
Vacuum system
Spare parts
Rolls
DST doctor & DST double doctor
Gear box & Drive gear
Various kinds of stretcher & Corrector
Drive shaft & Universal joint couplings
Paper machine designing & manufacturing
Paper machine remodification & boost
Paper machine erection & test-run
Paper machine ventilation system design &manufacturing
Rewinder supplies
Complete paper machine & equip spare parts supplies
Company Profile
Established in May 1988, is the production of pulp, paper, paper processing and sewage treatment professional equipment manufacturers, over the years to develop high-quality, high efficiency, energy saving, environmental protection and new products and services in the paper industry, scientific research production in one of the technology companies. Twenty years, the rapid development of enterprises, production capacity and production levels rising, widening the scale of production, has been awarded the contract and keep credibility of enterprises. Produced by the papermaking equipment selling more than 20 provinces and regions, and exported to Vietnam, Myanmar, Uzbekistan, Russia, Kyrgyzstan and other countries. By the user trust and praise.
