(1)RoHs&CE(2)OEM/ODM
(3)Industril panel
(4)Original high quality
(5)Almost to touch with any object
15inch 5wire Industrial panel high resolution touch screen panel
SPECS.
Technical characteristics
High accuracy and high resolution.
· Response is fast and high stability.
· Life of about four-wire resistance of 10 times.
Almost to touch with any object
· Waterproof, dustproof, anti-oil pollution, adapt to harsh environments
Technical characteristics
High accuracy and high resolution.
· Response is fast and high stability.
· Life of about four-wire resistance of 10 times.
Almost to touch any object
· Waterproof, dustproof, anti-oil pollution, adapt to harsh environments
Product Application
· PDA handheld device
· GPS satellite positioning system
Industrial control systems
· POS, financial terminals
Information kiosk
· Medical equipment service system
· Interactive Learning System
| MECHANICA | |||
| Key Specifications/Special Features | |||
| Surface hardness 3H jis 5400 | |||
| Optical clarity 80% | |||
| Operating temperatures -10 to 60°C | |||
| Endurance test strikes over 1 million | |||
| Operating voltage 5V DC | |||
| Resistance 200 to 900Ω | |||
| Linearity <2.5% | |||
| Faceplate surface anti-glare coating | |||
| Operating pressure 120 to 150g | |||
| Storage temperatures -40 to 90°C ( 60min cycle ) X ( 100 cycles ) | |||
| Message noise 5 to 15ms | |||
| Operating current 5 to 25mA | |||
| Isolation resistance 20MΩ at 25V DC | |||
| Compliant with RoHS ,CE,FCC Directive | |||
| OEM and ODM orders are welcome | |||
| All trademarks shown here are for reference purposes only. They are the property of their respective owners, and we are not authorized to sell items bearing such trademarks. | |||
| Download more information about this product | |||
