110v 220V AC COB LED 20w 30w 40w 50w AC COB led module

FOB Price

Negotiable / Piece

50 Pieces(Min.Order)

Supply Ability 100000 Piece / Pieces per Month
Port Shenzhen
Payment Terms:Credit Card

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price

Product Details

Place of Origin:

Guangdong, China

Brand Name:

FEDY

Model Number:

110v 220V AC COB LED 20w 30w 40w 50w AC COB led module

Product Description

110v 220V AC COB led high powr AC COB led

110v 220V AC COB LED 20w 30w 40w 50w AC COB led module

110v 220V AC COB LED 15w 20w 25w 30w AC COB led module

Item No.	Power	Emitting Size	Dimension	AC voltage	Intensity	CRI	Dimable
With wires behind , No need soldering---- 5W-20W
FD-2424-5	5W	Dia 23	24*24mm	110/220V	450-500	>75	Dimable
FD-2424-7	7W	Dia 23	24*24mm	110/220V	630-700	>75	Dimable
FD-2424-10	10W	Dia 23	24*24mm	110/220V	810-900	>75	Dimable
FD-2424-12	12W	Dia 23	24*24mm	110/220V	1080-1200	>75	Dimable
FD-2424-15	15W	Dia 23	24*24mm	110/220V	1350-1500	>75	Dimable
FD-2424-18	18W	Dia 23	24*24mm	110/220V	1620-1800	>75	Dimable
FD-2424-20	20W	Dia 23	24*24mm	110/220V	1800-2000	>75	Dimable
Illumination Diameter 11mm series -----5W-7W
FD-2022-5	5W	Dia 11	20*22mm	110/220V	450-500	>75	Dimable
FD-2022-7	7W	Dia 11	20*22mm	110/220V	630-700	>75	Dimable
Illumination Diameter 16mm series-----9W-12W
FD-2426-10	10W	Dia 16.5	24*26mm	110/220V	810-900	>75	Dimable
FD-2426-12	12W	Dia 16.5	24*26mm	110/220V	1080-1200	>75	Dimable
Illumination Diameter 20mm series-----5W-20W
FD-2630-5	5W	Dia 20	26*30mm	110/220V	450-500	>75	Dimable
FD-2630-7	7W	Dia 20	26*30mm	110/220V	630-700	>75	Dimable
FD-2630-10	10W	Dia 20	26*30mm	110/220V	810-900	>75	Dimable
FD-2630-12	12W	Dia 20	26*30mm	110/220V	1080-1200	>75	Dimable
FD-2630-15	15W	Dia 20	26*30mm	110/220V	1350-1500	>75	Dimable
FD-2630-20	20W	Dia 20	26*30mm	110/220V	1800-2000	>75	Dimable
Illumination Diameter 22mm series-----15W-30W
FD-3032-15	15W	Dia 22	30*32mm	110/220V	1350-1500	>75	Dimable
FD-3032-20	20W	Dia 22	30*32mm	110/220V	1800-2000	>75	Dimable
FD-3032-25	25W	Dia 22	30*32mm	110/220V	2250-2500	>75	Dimable
FD-3032-30	30W	Dia 22	30*32mm	110/220V	2250-2500	>75	Dimable
Illumination Diameter 25mm series-----20W-50W
FD-3040-20	20W	Dia 25	30*40mm	110/220V	1800-2000	>75	Dimable
FD-3040-30	30W	Dia 25	30*40mm	110/220V	2700-3000	>75	Dimable
FD-3040-40	40W	Dia 25	30*40mm	110/220V	3200-3600	>75	Dimable
FD-3040-50	50W	Dia 25	30*40mm	110/220V	4000-4500	>75	Dimable
Illumination Diameter 28mm series-----20W-50W
FD-3040-20	20W	Dia 28	30*40mm	110/220V	2700-3000	>75	Dimable
FD-3040-30	30W	Dia 28	30*40mm	110/220V	2700-3000	>75	Dimable
FD-3040-40	40W	Dia 28	30*40mm	110/220V	3200-3600	>75	Dimable
FD-3040-50	50W	Dia 28	30*40mm	110/220V	4000-4500	>75	Dimable
Illumination Diameter 25mm*4 series-----100W-200W
FD-3040-100	100W	Dia 25	85*110mm	110/220V	2700-3000	>75	Dimable
FD-3040-120	120W	Dia 25	85*110mm	110/220V	2700-3000	>75	Dimable
FD-3040-160	160W	Dia 25	85*110mm	110/220V	3200-3600	>75	Dimable
FD-3040-200	200W	Dia 25	85*110mm	110/220V	4000-4500	>75	Dimable

Part No.	Power	CCT	Intensity	Voltage	Current	CRI
FD-COB-3W	3W	3000K	250-280lm (230-250lm)	9.0—10.2V	350mA	≥70 (80)
FD-COB-3W	3W	5500K	290-310lm	9.0—10.2V	350mA	≥70
FD-COB-4W	4W	3000K	340-380lm(300-340lm)	12.0—13.6V	350mA	≥70 (80)
FD-COB-4W	4W	5500K	380-420lm	12.0—13.6V	350mA	≥70
FD-COB-5W	5W	3000K	420-480lm(380-420lm)	15.0—17.0V	350mA	≥70 (80)
FD-COB-5W	5W	5500K	480-530lm	15.0—17.0V	350mA	≥70
FD-COB-6W	6W	3000K	510-570lm(450-510lm)	18.0—20.4V	350mA	≥70 (80)
FD-COB-6W	6W	5500K	570-630lm	18.0—20.4V	350mA	≥70
FD-COB-7W	7W	3000K	600-660lm(520-600lm)	21.0—23.8V	300mA	≥70 (80)
FD-COB-7W	7W	5500K	660-730lm	21.0—23.8V	300mA	≥70
FD-COB-8W	8W	3000K	680-760lm(600-680lm)	24.0—27.2V	300mA	≥70 (80)
FD-COB-8W	8W	5500K	760-840lm	24.0—27.2V	300mA	≥70
Part No.	Power	CCT	Intensity	Voltage	Current	CRI
FD-COB-30W	30W	3000K	2300-2700lm	30.0—34.0V	900mA	≥80
FD-COB-30W	30W	5500K	2900-3200lm	30.0—34.0V	900mA	≥70
FD-COB-25W	25W	3000K	2100-2350lm	30.0—34.0V	750mA	≥80
FD-COB-25W	25W	5500K	2400-2650lm	30.0—34.0V	750mA	≥70
FD-COB-20W	20W	3000K	1600-1800lm	30.0—34.0V	600mA	≥80
FD-COB-20W	20W	5500K	2000-2200lm	30.0—34.0V	600mA	≥70
FD-COB-15W	15W	3000K	1300-1450lm	30.0—34.0V	450mA	≥80
FD-COB-15W	15W	5500K	1500-1650lm	30.0—34.0V	450mA	≥70
FD-COB-9W	9W	3000K	810-850lm	21.7—22.0V	450mA	≥80
FD-COB-9W	9W	5500K	880-930lm	21.7—22.0V	450mA	≥70
Part No.	Power	CCT	Intensity	Voltage	Current	CRI
FD-COB-16W-SS(Bi-color)	16W	3000K	500lm	24.0--25.0V	350mA	≥70
FD-COB-16W-SS(Bi-color)	16W	5500K	650lm	24.0--25.0V	350mA	≥70
