12-18*1W led driver

Specifications

12-18*1W led driver
Waterproof and no-waterproof
Constant current and voltage
ROHS ,CE

12-18*1W led driver





ROHS, CE

Available: Waterproof and no-waterproof
Available : Constant current and constant voltage
Available:  DC to DC, AC-DC.

Available AC INPUT: 110-130V, 85-265V, 200-220V, 12V ( DC and AC)

Available Output:  Do as your request !!!









power factor:	full load
effeciency:	>85%
drive mode:	Isolation
Technology:	no PFC,constant current,triac dimmable led dirver
current accuracy:	350mA ≤±3%(can do customized )
Temperature rise:	10~15 degree
certificate:	CE,ROHS,GS,UL
protection:	overload protection ,short circuit protection,over current ,over voltage protection , over temperature protection , can recovery when remove
working temperature:	30°~  +60°C
storage temperature:	40°~  +85°C
Hnmidity:	5%  ~  95%RH
Cooling method:	Nature cool
vibration resistance:	5 ~ 55HZ/2g 30 mins
impact resistance:	1g/S
MTBF	50,000 hours with full load condition
Safty:	EN55015/ CLASS B , *EN61000-4-2, EN61000-4-4, EN61000-4-5, EN61000-3-2 , IEC/ EN60968-1:2004+A1:2006 , IEC/EN60968-2-1:1989





Main advantages of FEDY

1. Have our own packaging technology,can control all details,with good quality and high brightness.

2. led with Low lighting attenuation,Conversion factor can reach 90%

3. Good glare control.

4. Special design good for heating output.

5. Long lifespan of up to 50,000 hours

6. We are professional manufacturuer with 12 years experience in leds . Quality Is 100% guaranteed.

7. Leds with  TW original Epistar chips amd Bridgelux chips from USA . Class A quality

8. With ROHS. With 2years warranty

9. Fast delivery .

10.  Experienced worker and fully equiped with automatic making machine and testing machines

11.  Experience technical staff with more than 10 years experience in led

12.  Quality control: led 100% tested before shipping

13.   Top quality raw material, All materials are strictly tested before usage.

14. Guarantee/warranty: 2 years

15.  Excellent packaging  :  50pcs/ESD box for without PCB, 35pcs/ESD box for with PCB

18.   Customaries design is available, free combination.



User guide:

Our product carried with 2 group wires , one is AC input wires with blue and brown color connect to"N" , "L" ,

the other one with RED and Black color connect to "+","-" Pin .



Attention:

If meet any problem with the goods pleasse contact us in time to reslove it .



1. application for LED tubes , led bulbs , led lighting ,  E27, E24, MR16  PAR30 ,PAR38, led bulbs etc.
2. Patent design. Long lifetime.
3. Designed base on UL/CE standard.
4. Constant current driver 6-25W LED tubes.
5. Open / short / over-current protection.
The product utilizes the Daliled Technologies innovative unique technologies specifically developed for the high power solid state lighting devices.
