Product Details
| Place of Origin | Jilin, China | Brand Name | CCRQ | |
| Model Number | high quality co2 laser focus lens | Material | Other, Glass, CVD Znse | |
| Usage | Optical | Structure | Other, Circular | |
| Shape | Plano |
Product Description
CO2 Znse laser focus lenses, Znse reflective mirrors
Co2 laser focus lens are made of USA imported CVD Zinc Selenide,which is produced by DOW chemical. USA made CVD ZnSe with sided AR-coated, whose main function is to decrease or eliminate the reflective light from lens, prisms, etc. and thus to increase these components transmittance rate and decline or eliminate stray light. Our focus lenses have advantages over than those of others, such as low laser power absorption rate, enduring high laser power density, stable surface coating film and wiping resistance. In CO2 laser industry common working band, 10.6 um, our laser lens transmittance rate is 99.8%.
As a most economical transmission laser focus components, laser focus lens is widely used in laser heat treatment, welding, cutting and infrared radiation collection. In order to obtain satisfactory performance and achieve the purpose that the surface of the lens should be towards the direction of imputed light beam towards the conjugate distance the longer end.
Technical Specifications:
| Material | CVD Znse |
| Diameter | 12.7mm 20mm |
| Dimension Tolerance | +/-0.15mm, +/-0.2mm, +0/-0.1mm as request |
| Parallelism | 3 arc minute(standard) |
| Radius | 3000mm |
| Surface Quality | 60/40 |
| Flatness | lambda/4 per 25nm at 632.8nm |
| Type | Circular.Meniscus |
| Edge | 0.2mm*45degree,others are available upon customer request |
| Coating | AR Coating at 10.6um |
