TDL5M Cell Culture Lab Centrifuge

Specifications

lab centrifuge
1.1 year warranty
2.wholesale price,fast delivery
3. LED&LCD display,operate date can auto-saved
CE&ISO

cell lab centrifuge

TDL5M cell culture lab centrifuge



Our company offical website:

We warranty our products for 1 year!                     skype: lucky.wendy90



1. Microprocessor control, operated by touch panel, LCD display, operated data can be saved automatically, RCF value can be set directly for working, easy to use.
2. Brushless converter motor which has high torque, high speed bearing from Europe, running smoothly and maintenance-free.
3. Steel body, stainless steel centrifugal chamber, good security and stability. Multistage damping system, low noise and slight vibration, green.
4. The freon-free compressor from Europe with high quality, stainless steel centrifugal chamber, Pre-cooling design for chamber makes cooling fast. high efficiency .
5. Equipped with overspeed, overtemperature, door interlock, unbalanced protection. The rotor can be disinfected at high temperature & high pressure, ensure safety.
6. blood bank centrifuge can be configured 5ml, 7ml, 10ml, 15ml, 30ml,50ml and several kinds of adapters, to meet the customer's different needs.



cell culture lab centrifuge technical parameter

Model	TDL5M
Max Speed	5000r/min
Max RCF	4390×g
Max Capacity	1000ml
Speed Accuracy	±50r/min
Temperature Range	-20°C to +40°C
Temperature Accuracy	±1°C
Time Range	0-99min
Power Supply	AC 220V 50Hz 18A
Noise	≤65dB
Instrument Dimension	640×680×380(mm)
Net Weight	95kg



cell culture lab centrifuge rotor:

Rotor Type	No.	Capacity	Max Speed (r/min)	Max RCF(×g)	Tube Dimension (mm)
Swing Rotor	No.63	4×50/100ml	5000	4390	Ø38×124
	No.70	4×250ml	4000	3500	Ø64×113
		Adaptor:8×50ml
		Adaptor:32×10ml
	No.77	32×10/15ml	4000	2810	Ø16×85-118
	No.81	8×50/100ml	4000	2810	Ø38×124
	No.82	48/40×5ml	4000	2800	Ø14×54
	No.85	96×7ml	4000	2800	Immuno Tubes
	No.85	80×7ml	4000	2800	Vacuum Blood Collection Tube



Remarks: If you have any question please feel free to contact me.

skype: lucky.wendy90

Product photos



Details components in the centrifuges



Danfoss checking valve for centrifuge



SKF bearing in the power-driven machine for centrifuge



Packing and delivery
