Mechanical shock tester Drop Ball Impact Tester

Name: Mechanical shock tester Drop Ball Impact Tester
Brand: ASLi
Availability: InStock

FOB Price

USD $36,000 - $125,000 / Set

1 Set(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Guangdong, China	Brand Name	ASLi
Model Number	MS series	Power	Electronic
Usage	Other, Impact Testing Machine, Impact Testing Machine

Mechanical shock tester Drop Ball Impact Tester

machine view

Why do we need Mechanical shock tester Drop Ball Impact Tester

It is common for military component manufacturers and telcom equipment manufacturers subject their

products to mechanical shock testing. This will help ensure that shocks or repetitive shock pulses do not

affect the operating characteristics or cause physical damage. Device manufacturers also shock test

during the design verifIcation testing stage to find design flaws before going into production.

Mechanical shock tester Drop Ball Impact Tester Technical Parameters :

Model	MS-50	MS-100	MS-200	MS-500		MS-800
Load Capacity (kg)	50	100	200	500		800
Pulse Acceleration( m/s2)	50~1200	50~1000	50~1000	50~500		50~500
Pulse Width (ms)	20~3	20~3	20~3	20~3		20~3
Frequency (times /min)	10~80	10~80	10~80	10~80		10~80
Table Size (mm)	500X700	700X700	700X700	800X800		1000X 1000
Max. Dropped Height (mm)	60	60	60	60		60
Pulse Type	Half Sine wave, (trapezoidal wave, and the sawtooth wave, square wave optional)
External Dimension WXHXD (mm)	800X1300X 1000	800X1300X 1000	850X1350X 1100		1000X1300X 1900	1000X1300X 1900
Weight (Kg)	1100	1250	2000		3000	3500
Protection Device	Door protection, over-load protection, zero signal protection
Power	AC 220V(±10%), 1&3 Lines ,50/60HZ; AC 380 V(±10%) ,3 & 5 Lines,50/60HZ
Environmental Conditions	Temperature: 25°C±5.0°C humidity: <85%(25°C)
