Sand & Dust Test Chambers

Name: Sand & Dust Test Chambers
Brand: ASLi
Availability: InStock

FOB Price

USD $4,000 - $10,000 / Set

1 Set(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Sand & Dust Chambers

Sand & Dust Chambers Technical Parameters :

Model	DT-F1	DT-F2	DT-F3	DT-C1	DT-C2
Remark	F for floating dust			C for cyclone dust
Concentration of Sand and Dust	F1: 60000mg/m3	F2: 3000mg/m3	F3: 100mg/m3	C1: 5000mg/ m3, 5m/s	C2: 100mg/ m3, 10m/s
Internal Dimension WxHxD (mm)	1000x1000x1000			1000x1000x1000
External Dimension WxHxD (mm)	1600x1800x1300			1650x1850x1450
Temperature Range	RT(25°C±15°C), or lab temperature			RT(25°C±15°C), or lab temperature
Humidity Range	35~90% R.H., or lab humidity			35~90% R.H., or lab humidity
Talcum Powder Dosage(Kg/m ²)	2 ~4
Metal Net Mesh Standard Diameter(μm)	50
Diameter Between Metal Wires(μm)	75
Powder Spray & Dust Fall Mode	1.Dust fall freely: adopt centrifugal fan to blow the sand or dust to the 1/5 of roof, then fall freely. 2.Blow the sand or dust: pressure spray dust from the bottom, multi-steps pressure adjustable
Test Standard	Meet JIS, ISO, IEC60529,DIN40050,GB2423 test standard
Power	AC 220V(±10%), 1, 3 Lines,50/60HZ ;
