Unitube Light-armored Fiber Optic Cable (GYXS/GYXTW)

Detailed Info
Central Loose Tube Cable GYXTW, 2~12 fibers, jelly filled and fiber contained central loose tube, copolymer coated steel tape, two parallel steel wires 1.2mm, PE outer sheath, G652D SM fiber, detailed specification on your request.

Description
Single jelly compound filled loose tube containing up to 24 fibers color code as per color coding scheme. surrounded by moisture barrier bonded to polyethylene incorporating two steel wire strength elements. This cable is suitable for outdoor duct, direct burial or aerial applications

Features :
(1) Low dispersion and attenuation
(2) Proper design, precise control for fiber excess length and distinct stranding process render the cable excellent mechanical and environmental properties
(3) The armoring of corrugate steel tape make cable have nice properties of moisture resistance and crush resistance
(4) With small cable diameter, light cable weight, easily to lay
(5) Operating Temperature : -40~+60 °C

Packaging Detail:  Wooden drum or iron wooden drum

Delivery Detail: 30 days after confirmation of order and payment

In 1995, first test run of Huiyuan ADSS cable put into operation in Sichuan power grid.  After nearly 20 years test, the line still runs safely, which creates the longest run record of domestic ADSS cable.

In 1996, the first domestic ADSS cable with high-voltage electrical corrosion sheath ran safely on the 220KV line till so far.

After years of development, Huiyuan has become a special optical cable provider in the western region and an influential company in China. Its featured products have four series, including power fiber optic cable (ADSS, OPGW, OPPC); micro air blown cable, fiber optic unit and micro air blown cable tube; various types of sensing cable and detection cable; Lp user oriented fiber and optical fiber ribbon.

1. We are one of the biggest optical fiber cable manufactures in China and have 20 years’ manufacturing and selling experience.

2.Micro air blown fiber optic cable, OPGW and ADSS are our competitive products.

3. We accept OEM. The cable size and material are customized.

Your own logo and own design are welcomed.
We will produce according to your requirement and description;

4. Different ways of transportation

A. ROAD, RAIL, SEA, and AIR transport.

B. Air Express: FedEx, DHL, UPS, GLS, and so on.

5. We provide FREE samples.

6. Please send us inquiry for more products info and we will give you feedback in 12 hours.

For any questions, please feel free to contact with Roy.

Email: huiyuan_roy(at)
