uk Used Desiccant Air Dryer for Sale

Guangdong TAYQ Gas Equipment Co., Ltd.
uk Used Desiccant Air Dryer for Sale thumbnail-1
uk Used Desiccant Air Dryer for Sale thumbnail-2
uk Used Desiccant Air Dryer for Sale thumbnail-3
uk Used Desiccant Air Dryer for Sale thumbnail-4
uk Used Desiccant Air Dryer for Sale thumbnail-5
uk Used Desiccant Air Dryer for Sale thumbnail-6
uk Used Desiccant Air Dryer for Sale photo-1
uk Used Desiccant Air Dryer for Sale photo-2
uk Used Desiccant Air Dryer for Sale photo-3
uk Used Desiccant Air Dryer for Sale photo-4
uk Used Desiccant Air Dryer for Sale photo-5
uk Used Desiccant Air Dryer for Sale photo-6
US$ 100 - 1,000 MOQ: 1 Unit
Key Specifications
Get Latest Price
Condition:
New
Type:
Freeze Drying Equipment
Place of Origin:
Guangdong, China
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
SHENZHEN OR GUANGZHOU
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Freeze Drying Equipment
Place of Origin Guangdong, China
Brand Name TAYQ
Model Number TQ-600XFW
Voltage 380V
Power(W) 18KW
Dimension(L*W*H) 2400*1450*2750mm
Weight 3520kg
Certification CE ISO
Warranty 1 Year
After-sales Service Provided No overseas service provided

TQ Seris psa nitrogen generator high quality and  low price



professinal manufactory over 15 year experinces
low running coat ,low pressure drop and steady dew point.microprocessor control.,hmi touch screen easy operate.

heatless adsoption air drer and micro heated asorption air dryer best price with high quality

Adsorption air dryer professinal manufacturer lowest price



Principle:

With drop force of bottom impact and side vibration, the manufacturer tightly fill the senior moisture-absorption chemical raw materials-molecular (Alumina) inside both drying towers. When the Moisture-Contained gas impacts the sorbent in a curve following specific flow direction, the vapor water in the air will be absorbed under the pressure state. The water will be released automatically from the sorbent with the instant pressure drop method when the sorbent absorbs the water and saturated. Just by this characteristic, this product works alternatively in the sequence of absorbing, releasing, regenerating and charging in the manner of shifting between two towers.





Features



1. The excellent design of the two tower or use our patent there towers desigh high efficiency

 It can ensure activated aluminium oxide contact time enough to dry the saturated wet air entering in dryer to the needed dew point, 30% extra desiccative can compensate the desiccative consumption and ensure the life time, then guarantee the best performance

2. Adopts the large scale diffuser

    To ensure the air stream well proportioned to get through the desiccative level

3. Reliable controlling system

   3.1 Within 10 minutes period dry the compressed air to very low dew point of -40°C or within 4 minutes period dry  to -70°C,and can be conditioned at site

   3.2 Micro CPU control way , and the PLC control is optional

4. System Pressure drop is lower than 0.02MPa

5. Easily operation & easily maintenance

     Power on-off switch, the period mode setting, power on light, regenerative on light



Technical parameters

Rated Inlet Temperature: ≤38°C
Maximum inlet temperature: ≤70°C
inlet oil content: ≤0.1ppm
Outlet Pressure Dew Point: -20°C (-70 °C below zero is optional)
Adsorbent: Activated alumina or molecular sieve
 Rated Working Pressure:0.5~1.0MPa(1.0MPa or above is optional)
Pressure loss: 0.07MPa
Control Model: CPU (standard configuration), PLC is optional
Working Mode: Automatic switching between tower A and tower B, continuous working
Regeneration Way: Heatless regenerative
Regeneration Air Consumption: 3-8%
Cycle Period: 10~90min, adjustable
Power Supply: 220V/50HZ/60hz,380v/50hz-60hz



TQ Series heatless adsorption air dryer technical data
Model NoCapacity(m³/min)WeightKG)Outlet diameter(mm)Desicative(KG)Power(W)Voltage(V)Dimension(MM)                       (L×W×H)
TQ-10XF1.3135202550220V 50-60Hz 800*550*1680
TQ-20XF2.6205255550220V 50-60Hz 800*550*1680
TQ-30XF3.8265259050220V 50-60Hz 900*600*1780
TQ-50XF6.83704015560220V 50-60Hz 1050*650*2000
TQ-60XF7.64254017560220V 50-60Hz 1050*650*2000
TQ-75XF10.54805025060220V 50-60Hz 1150*700*2250
TQ-100XF14.56305030560220V 50-60Hz 1250*750*2280
TQ-150XF21.69456538560220V 50-60Hz1450*950*2600
TQ-200XF28.512506553060220V 50-60Hz 1550*1050*2650
TQ-250XF33.515808064570220V 50-60Hz1600*1100*2500
TQ-300XF38.018608072570220V 50-60Hz 1650*1150*2550
TQ-350XF45.022008086070220V 50-60Hz 1900*1200*2650
TQ-400XF51.0247010091080220V 50-60Hz2100*1250*2750
TQ-450XF58.02780100105080220V 50-60Hz 2150*1300*2750
TQ-500XF66.03200100121080220V 50-60Hz 2200*1350*2750
TQ-600XF75.03350125136080220V 50-60Hz 2400*1450*2750
TQ-700XF86.037801251600100220V 50-60Hz 2400*1500*2800
TQ-800XF95.041001501850100220V 50-60Hz2450*1550*2800



TQ Series micro heated adsorption air dryer technical data
Model NoCapacity(m³/min)WeightKG)Outlet diameter(mm)Desicative(KG)Power(W)Voltage(V)Dimension(MM)                       (L×W×H)
TQ-10XFW1.314520221220V 50-60Hz 800*550*1680
TQ-20XFW2.621525481.5220V 50-60Hz 800*550*1680
TQ-30XFW3.827525801.8220V 50-60Hz 900*600*1780
TQ-50XFW6.6395401202.3220V 50-60Hz 1050*650*2000
TQ-60XFW7.6450401352.6220V 50-60Hz 1050*650*2000
TQ-75XFW10.5520502153380V 50-60Hz1150*700*2250
TQ-100XFW14.5660502503.5380V 50-60Hz1250*750*2280
TQ-150XFW21.6980653304.6380V 50-60Hz1450*950*2600
TQ-200XFW28.51285654505.5380V 50-60Hz1550*1050*2650
TQ-250XFW33.51615805807380V 50-60Hz1600*1100*2500
TQ-300XFW38.01990806308.5380V 50-60Hz1650*1150*2550
TQ-350XFW45.022508080010380V 50-60Hz1900*1200*2650
TQ-400XFW51.0252010084012380V 50-60Hz2100*1250*2750
TQ-450XFW58.0281510092014380V 50-60Hz2150*1300*2750
TQ-500XFW66.03250100106015380V 50-60Hz2200*1350*2750
TQ-600XFW75.03520125121018380V 50-60Hz2400*1450*2750
TQ-700XFW86.03850125145022380V 50-60Hz2400*1500*2800
TQ-800XFW95.04200150170026380V 50-60Hz2450*1550*2800









Drawing

uk used desiccant air dryer for saleuk used desiccant air dryer for sale



Pictures

uk used desiccant air dryer for saleuk used desiccant air dryer for saleuk used desiccant air dryer for saleuk used desiccant air dryer for saleuk used desiccant air dryer for saleuk used desiccant air dryer for saleuk used desiccant air dryer for sale





uk used desiccant air dryer for saleuk used desiccant air dryer for saleCertificate and honor

uk used desiccant air dryer for saleuk used desiccant air dryer for saleuk used desiccant air dryer for saleuk used desiccant air dryer for sale
