Pit type vacuum gas carburizing furnace

Brief

     RQ3 series pit type vacuum gas carburizing furnace is new type and energy-saving batch type furnace,working temperature is 950℃,mainly used for rod and long axis steel mechanical parts for gas carburizing,the workpiece is vertically loaded in furnace tank,not easy to deformation

Structure

     RQ3 series pit type vacuum gas carburizing furnace is mainly composed of furnace shell, furnace lining, heating device, muffle tank, loading frame, the furnace cover, and furnace cover lifting mechanism, etc. Furnace body is cylindrical deep well, workpiece is vetically loaded in furnace tank for heating,Pit type furnace is usually placed under the ground plane in the workshop, also is placed above the ground plane, or ground level fluctuation in each half.

      This series cann also be used for machine parts for quenching, tempering, annealing, normalizing, carburizing and carbonitriding heat treatment.etc, Electric or gas can be used for heating, if electricity is used as heat source, known as well type resistance furnace.

Main technical parameters

Note: Various size pit type quenching furnace can be designed and manufactured as user's needs.
