Best-Selling MPEG4 (1080P) h.264 hd encoder ip video encoder

FOB Price

USD $1,000 - $2,000 / Set

1 Set(Min.Order)

Supply Ability 1000 Set / Sets per Month
Port Shanghai/Hangzhou
Payment TermsT/T Credit Card PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Zhejiang, China		Brand Name	Dibsys
Model Number	ENC3311

Product Description

ENC3311 a create a single H.264 channel on your building,campus or metropolitan-area IP network from the output of various video devices. These include video cameras,DVD/Blu-ray players, digital signal systems, personal computers and even set-top boxes for premium TV channels. Encoder blades are available for both SD and 1080P HD MPEG4 AVC encoding.. It is equipped with the latest advances in video compression technology to deliver unsurpassed video quality at lowest bitrates, and low latency to achieve high image quality video and audio transmission,fully support for SDI/ HD-SDI, Composite, HDMI, YPbPr, S-Video interface inputs encoding, both IP and two identical ASI data outputs. It also can be used to support IPTV, broadcast and video surveillance applications.

The ENC3311’s highly bandwidth efficient MPEG-4 CBR encoding and native IP output make it possible to deliver exciting and competitive HD services to broadcast operators

Feature

1.Advanced MPEG-4 AVC HP@L4, MP@L3 video compression

2.ASIC technologies which offer broadcast video quality, generally video bitrate advised: SD about 1.2mbps, 720p about 2mbps,1080 about 6-8mbps for lowest bitrates

3.HDMI 1.3a interface, Auto detect the HDMI input of resolutions

4.Support the importation of SDI/HD-SDI, HDMI, CVBS, S-Video, YPbPr encoding

5.Audio sampling Rates: 48KHz

6.MPEG-1 Layer2 , HE-AAC(V2) (option)or LC-AAC(option) audio encoding

7.Supports unicast and multicast IP output UDP protocol as well as two identical ASI outputs

8.Management via External SNMP and local front panel

9.Supports resolution:1080P/i@50/60Hz, 720p@50/60Hz, 480i, 576i

10.Built-in time base correction and video pre-processing

11.Easy-to-Use System Management

Input
Video Input	1 x Composite level: 1.0Vp-p, Impendence,75Ω,BNC
	1 x S-Video Analog Component Video Interface
	1 x Digital SMPTE 292M (HD-SDI) digital video, BNC
	1 x HDMI 1.3a
	1 x YPbPr component video interface, Connector: BNC
Audio Input	2 analog stereo audio, BNC interface (unbalanced)
	HDMI/SDI embedded audio

output
	DVB Interface: Two identical ASI, Comply to EN 50083-9 ASI Standard, BNC, 75Ω
	IP output: 100M Base-T Ethernet UDP/IP output, Multicast/Unicast supported
	Output Format: 188 bytes, 7x188 bytes per udp packet
	Output Rate: 0.8Mbps~20Mbps

Video Encoding
	Comply to the International standard:MPEG-4 AVC High Profile, Level 4,Main profile Level 3.0 Aspect ratio:16:9(HD),4:3(SD)
	Scene change detection
	Bit rate mode: VBR,CBR
	Brightness / Contrast / Saturation / Chroma /Horizontal Offset
	GOP Structure: IBBP

Audio Encoding
	Sampling Rates: 48KHz
	Bit rate:64, 128, 192, 256, 384kbps
	Audio encoding: MPEG-1 Audio Layer
	Quantization:24bit
	Stereo or single channel
	Audio Gain: 0-16

Resolution
	Accordance to CCIR601 standard
	1920x1080p/i,1280x720p,720x480p,720x576p

Management
	10/100 Base T Ethernet, RJ45, SNMP
	7 keys:UP,DOWN,LEFT,RIGHT,ENTER,ESC,Lock
	Front-panel LCD configuration, LED indicate light
	SNMP protocol support

Environment
	Radiation safety requirements and comply with GB13837-92 and GB8898-88 standards
	Power Supply: AC 90-250V 50/60Hz
	Power consumption: 20W
	Operating temperature:-10 - 50°C
	Storage temperature: -10 - 75°C
	Dimensions: 455(L)x483(W)x 44mm(H) (1RU)
	Weight: 5kg

Order informations
ENC3210	Single Channels HD/SD Encoder/Transcoder
ENC3240	Four Channels Broadcast HD Encoder HDMI
ENC3245	Four channels Broadcast HD Encoder HDMI+HDSDI Inputs
ENC3211	1Ch MPEG-4 AVC HD Encoder
ENC3311	ingle Channels Full HD/SD Encoder
ENC3341	Four channels Professional Full HD Encoder HDMI Inputs

ENC3111

ENC3345

ENC3245
