Pipe Insulation Blanket

Specifications

1. Heat insulation blanket for pipes, valve, elbow, flange, die moulds
2. Save 40% energy
3. Easy to install
4. Removable

  Description:



The thermal insulation jacket/blanket/cover is used especially on industrial applications, e.g. plastic (extrusion, injection, blow moulding) industries, construction, etc. It can be customized according to customer requirement, e.g. the design of the applied products. It is very flexible to use and easy to install.



The insulation jacket offers a cost efficient solution which can save energy consumption to 30%. And it can lower the temperature of the products which can prevent operators from burning or scalding.



The removable thermal insulation jackets (covers) can be fabricated in many different ways depending on the materials used, the application and the customer requirements. Usually, The removable thermal insulation jacket consists of surface layer, insulation layer, and liner and/or anti-abrasion layer inside. Seams are sewn with high temperature threads, usually with Kevlar TM, PTFE coated glass fiber or stainless steel thread to suit application.



The service temperature depend upon the different materials used, the highest temperature is 1200(C).

Typical applications are including:
        · Barrels of injection, extrusion, blow moulding and filming machines

        · Steam turbines, gas turbines (as turbine blankets) and compressors
        · Exhaust systems of engines, Generators
        · Heat exchangers

        · Pumps, Valves & Flanges
        · Expansion Joints, Flex Hose
        · Tank Covers
 Please see blow a chart showing the energy saving calculation.





Please send us the specifications of the applied objects, e.g. the inner, outer diamter of the heating bands, etc.
