UVSS Detecting dangerous weapon under the vehicle

  UVSS Detecting dangerous weapon under the vehicle

Embedded Under Vehicle Surveillance System XJCTB-2009

Software:
1, Using linear CCD scanning technology Dynamic imaging;
2, Chassis image display time: <1 second; (length of vehicle 5 meters);
3, Store or load time: <1 second;
4, Image magnifying multiples: > 2 times; (lossless enlarge)
5, Image resolution: > =2,000,000 pixels;

System host server and monitor :
1, Display: 22 inch TFT 1680 x 1050 LCD screen
2, CPU: INTEL Core Duo processor
3 , Motherboard : dedicated server motherboard
4 , Memory : DDR II , more than 2GB
5 , Hard disk : 500G serial port high-speed hard disk

License plate recognition system ( Please provide us the recognition software and database locally before shipment.  )
1, Standard 1 channel license plate recognition module, can be optionally extended to two or more channels ;
2, A single character recognition accuracy rate : ≥ 99%;
3, Average recognition time : <20ms;

4, Whole plate recognition accuracy rate : ≥ 95%
5, The image of license plate allows horizontal tilt angle: -10 to +10 degrees ;

For more details,please contact us on-line.
