Home > Products > pasta machine > Stainless steel macaroni past machine
Stainless steel macaroni past machine
- 40 Set / Sets per Month
- qingdao port
- T/T
Product Details
Condition: | New | Place of Origin: | Shandong, China | Brand Name: | SBN |
Model Number: | DLG Macaroni Pasta Machine | Application: | Other, macaroni past machine | Voltage: | It is according to clients local voltage |
Power(W): | 100kw | Weight: | 7000kgs | Dimension(L*W*H): | 22mx2mx4m |
Certification: | CE SGS | Warranty: | One Year | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Packaging & Delivery
Packaging Details: | wooden case for export,fit for multiple handing and long distance marine shipping |
Delivery Detail: | within 30 days or less |
Specifications
pasta processing line
1.can product macaroni/italian pasta and spaghetti pasta
2.supply the basic formula
3.CE,ISO
Introduction
The macaroni production line mainly use flour, starch as raw material. We are using unique extrusion process, many popular shapes in market, the rational design of the production line, There are fully automatic, precisely control system, the host with the high and low pressure screw, to increase the range of use of raw materials, to reduce the cost and improve the product quality
Products
This line can be used to produce screw, shell, round tube, square tube, bend tube and so on.
Raw materials:Wheat flour.
Capacity:100-120kg/h and 280-300kg/h
Machine material:All the machines are made by Stainless steel 201,If you have special requirement, we also have ss304,ss316.
Voltage:Chinese Input Voltage is 380V/ 50Hz /3, If it is different from yours , we will adjust it .
Process Flow:Mixer---screw conveyor---single screw extruder---cutting machine---cooling conveyor--- oven---cooling---(packing machine)
Technical parameter
Model | DLG110 | DLG150 |
Install capacity | 110kw | 180kw |
Power consumption | 80kw | 110kw |
Output | 100-120kg/h | 280-300kg/h |
Size | 19000*2000*2200mm | 22000*2000*2200mm |
Technical parameter of machine
No | Machine | Function |
1 | Name: Mixer Power:4kw Dimension(m):1.1×0.8×1.4 | The mixer wall and bottom are welded as a whole part to avoid material spilling. Stainless steel mixer shaft in the mixer tank to mix the raw material,water and other additives. |
2 | Name: Screw conveyor Power:1.1kw Dimension(m):1.7×0.6×2.2 | The raw material can be conveyed in the stainless steel roller without any leaking, dust pollution.The machine not only saves labor, but also improves automatic degree of processing line. |
3 | Name: DLG110 Single screw extruder Total Power:42kw Dimension(m):2.6×0.9×1.9 | 1.Feeding system:0.75KW motor drive the screw in the feeder,then move the material into the extruderThe feeding speed is digitally controlled. 2.Extruded system: 22KW main motor drive the gear box,then run the screw.The screw thread is loose then tight.The pressure of barrel will be stronger to cook and shape the raw material. The extruded speed is digital controlled. 3.Heating and cooling system:There are some heating ring and cooling water jacket outside of the barrel.Thermocouple measure the barrel temperature all the time,the heat or cool the barrel automatically. 4.Vacuum system: Follow the Europe and America technology,adopt special vacuum pump draw out the air inside the barrel.This technology will avoid the bubble inside the pasta product,make the pasta glossy and chewy. 5.Cutting system:1.1KW motor drive the knife block with the knife,then cut the pasta out of the mould into various shapes.The cutting speed is digital controlled. |
4 | Name: Convey cutter Total Power:1.25kw Dimension(m):2.7×0.7×1.2 | The raw material will be extruded in circular tube,then pull the circular tube into the shaper. Cooling ,rolling and cutting it into many piece.
|
5 | Name :Sifter Power: 0.25KW Dimension(m): 1.5×0.8×0.6
| The sifter connect the extruder or cooling cuter and oven.After product drop to the sifter, it will sift and help to drop the product into oven evenly and well-distribute,which has the function of distributor. |
6 | Name: Elevator & Oven (7 layers 8 meters) Dimension(m):8.4×1.3×2.2 Drying temperature:10—180 Heating power:80kw | The moister in the food which come out of the extruder is about 12 to18%. With the dry of the dryer, the moister can get down below 8% and this is easy to be storage for long time.There are heating system and convey system.Some times there is also blower here in order to dry the food fast according to the condition. |
7 | Name :Cooling Conveyor Dimension(m): 5.0×0.7×1.1 Power: 0.37kw | After the product came out from the oven, the product still has some temperature, before packaging, it is better to cool it, the cooling conveyor with several cooling fans can finish this work.With stainless steel belt and adjustable running speed. |
About installation and after-sale service system:
1. We can provide factory layout according to customer’s factory size in advance.
2. When we received your deposit of this order, we will ask our engineers to prepare to apply the visa, when the corn flakes processing line arrived your country, and we will send two engineers to go and help you to install the corn flakes line, teach your worker(3-4 workers) how to operate the corn flakes line, until your worker know the corn flakes line well.
3. Our engineers has responsibility to teach your worker how to clean the extruder, how to change the screw, how to change barrel etc. and we have responsibility to provide technology support with you forever.
4. Our engineers can provide basic formula for producing the corn flakes, breakfast cereals, snack food etc. and help customer to produce good quality food according customer’s detailed formula.
5. We provide the spare parts will at preferential price for an extended long time.
6. other item:
a). Free consultation service before, during, and after sales;
b). Free project planning and design services;
c). Free debugging of equipment until everything is functional;
d). Free management of equipments' long distance shipping;
e). Free training of equipment maintenance and operating personally;
f ). Free new production techniques and formulas;
g). Provide 1 year complete warrantee and life-time maintance service;
